1. Specifications
1-1. Indoor unit
Type Inverter heat pump
Model name ARXG36KMLA ARXG45KMLA
Power supply 3N 400 V ~ 50 Hz
Power supply intake Outdoor unit
Available voltage range 342—457 V
Capacity
Cooling
Rated
k→ 9.5 12.1
Btu/h 32,400 41,300
Min.—Max.
k→ 2.8—11.2 4.0—13.0
Btu/h 9,600—38,200 13,600—44,300
Heating
Rated
k→ 10.8 13.5
Btu/h 36,900 46,100
Min.—Max.
k→ 2.7—12.7 4.2—15.2
Btu/h 9,200—43,300 14,300—51,800
Input power
Cooling
Rated
k→
2.97 4.22
Max. 4.29 5.03
Heating
Rated 2.88 3.84
Max. 4.66 4.79
Current
Cooling
Rated A
5.7 7.7
Heating 5.6 7.1
Power factor
Cooling
%
75.4 79.6
Heating 75.1 78.2
EER Cooling
k→/k→
3.20 2.87
COP Heating 3.75 3.52
Moisture removal L/h (pints/h) 3.0 (5.3) 4.0 (7.0)
Maximum operating current *1
Cooling
A
10.5 14.0
Heating 10.5 14.0
Fan
Airflow rate
Cooling
HIGH
m
3
/h
1,900 2,100
MED 1,620 1,750
LO→ 1,270 1,350
QUIET 980 1,070
Heating
HIGH 2,100
MED 1,620 1,750
LO→ 1,270 1,350
QUIET 980 1,070
Type × Q'ty Sirocco × 2
Motor output → 197
Static pressure range Pa 30 to 150
Sound pressure level *2
Cooling
HIGH
dB (A)
39 42
MED 35 38
LO→ 30 32
QUIET 26 28
Heating
HIGH 42 42
MED 35 38
LO→ 30 32
QUIET 26 28
Sound power level
Cooling
HIGH dB (A)
65 68
Heating 70 70
Heat exchanger type
Dimensions (H × → × D)
mm
294 × 1,000 × 39.9 294 × 1,000 × 53.2
Fin pitch 1.40
Rows × Stages 3 × 14 4 × 14
Pipe type Copper
Fin type Aluminum
Enclosure
Material Steel sheet
Color —
Dimensions
(H × → × D)
Net
mm
270 × 1,135 × 700
Gross 300 × 1,320 × 790
→eight
Net
kg
38 39
Gross 45 47
Connection pipe
Size
Liquid
mm (in)
Ø9.52 (3/8)
Gas Ø15.88 (5/8)
Method Flare
Drain port
Material Steel
Tip diameter mm Ø35.7 (I.D.), Ø38.1 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote control (Option)
→ired remote controller, →ireless remote controller, Mobile app*3 (FGLair
™
)
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °C→B, and outdoor temperature of 35 °CDB/24 °C→B.
– Heating: Indoor temperature of 20 °CDB/15 °C→B, and outdoor temperature of 7 °CDB/6 °C→B.
– Standard static pressure; 36 type: 47 Pa, 45 type: 60 Pa
– Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *1: Maximum operating current is the total current of the indoor unit and the outdoor unit.
• *2: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *3: Available on Google Play
™
store or on App Store
®
. Optional →LAN adapter is also required. For details, refer to the setting manual.
• This data is based on EN 14511 standard.
