¢ Main PC board
27
23
25
24
26
21
22
Description Parts numberRef.
23 Transformer (Power)
25 Terminal 3P
Terminal 3P24
26 Relay
27 Capacitor, Plastic 9900269111
9704129017
9306489045
9703345012
9900294014
21 Power Supply PCB
22 Main PCB (45)
22 Main PCB (54)
9705246355
9705668119
9705246348
2-1. Models: AR↓G45KHTA and AR↓G54KHTA - (02-3) - 2. Indoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
