PARTS LIST
34 Fan Capacitor (2.5MF 450V) 9900270186
56 Sirocco Fan Assy
9358621004
63 Panel Assy Front 9363722000
67 Rubber (Vibration-proof)
313659068604
74 Air Filter 9366833017
109 Casing Assy
9363322002
126 Bracket (Motor) Assy
9358591000
138 Panel Assy (Motor) 9363193008
143-1 Clamp NK-3N
313361274700
146 Evaporator Assy 9373255031
147 Distributor Assy 9373034070
160 Drain Pan Sub Assy 9364502014
164 Motor, Induction (MFA-09NTAT) 9600778203
173 Hook Metal 9363195002
184-1 Thermostat Spring-A 313728262708
195 Binder-C (SKB-100) 313361275805
196-2 Binder-M (SKB-150) 313035356905
232 Coupling Pipe Assy 9373038078
234 Thermistor (Room) 9703299063
235 Pipe Thermistor 9703297090
236 Controller PCB Assy 9704557995
(K01AL-0413HSE-C1)
240 Remote Control Unit (AR-3TA1) 9372266014
244 Cover (Piping) 9363330007
287 Cap (Power) 9352173011
320-1 Wire Clamp Metal 313483219905
338 Bracket (Motor) 9358594001
380 Locking Spacer KGLS-6S 313209391403
381-4 Spacer KGPS-6S 0600118075
455 Control Box 9366299004
464 Cabinet Cover Sub Assy 9364503011
514 Control Box Cover 9363201000
567 Support Plate (Eva. ) 9363323009
588-1 Bracket Eva. R 9363199000
588-2 Bracket Eva. L 9363198003
625 Cord Bush 9359240006
734 Top Panel Sub Assy 9364507019
761 Side Panel Right Sub Assy 9364505015
762 Side Panel Left Sub Assy 9364506012
815-1 Terminal 7P 9703403019
875 Filter PCB Assy 9704561251
982-1 Clamp (Cord) 9356857009
982-2 Clamp (Cord)-B 9356858006
When you order parts, please make a photocopy of this page and
fill the number of the parts in the "Order" column.
INDOOR UNIT
Ref.
No.
Description
Ord.
Q'ty
Part No.
ARY9LUAB
18
2005.07.07
To Next Page
