Fujitsu ARY9LUAB User Manual

When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
OUTDOOR UNIT
2 Fan Guard 9371187013
4 Emblem 9351355005
5 Front Panel Painted 9371924014
7 Connecteor Cover (Cabinet) 9366398004
Inverter Assy
45-1 Motor Bracket 9371929019
45-2 Motor Bracket-Top 9371931012
45-3 Motor Bracket-Ctr 9371930015
45-4 Motor Bracket-Bottom 9371932019
46 Compressor Assy 9373262015
Ref.
No.
Description
Ord.
Q'ty
Part No.
12 Base Assy, Painted
9371920078
13-1 3-Way Valve
9372205044
13-2 2-Way Valve 9372204054
16 Condenser Assy 9372181096
26-1 Compressor Cover A 9373730019
26-2 Compressor Cover B 9373730026
31 PWB Assy 9705285019
29 Separate Wall 9372795019
17 Thermister Holder Pipe 313714262805
39 Propeller Fan Assy
9366378013
41 Motor Induct 9601671046
33 Control Cover 9372792018
--- Capacitor for PCB 9705387010
--- Fan Capacitor 9900270049
--- Fuse 0600086039
--- Terminal 8P 9900203047
--- Fuse Holder 0501454012
--- Terminal 2P 9701971015
--- ACTPM 9703457012
31 Controller PCB Assy 9705285019
Ref.
No.
Description
AOY24LMAM2
Ord.
Q'ty
Part No.
AOY24LMAM2
754 Washer (Rubber) 9358078006
--- Compressor pressure switch 9900186012
--- Compressor thermal switch 9373263012
--- Thermistor Valve 9900194017
--- Thermistor discharge 9704219039
--- Thermistor outdoor 9703516047
--- Thermistor heat sink 9900195014
--- Heat exchanger thermistor 9704220059
411 Gasket 9373266013
527
Protective Net 9371934013
734
Top Plate 9371925011
735-3
Capillary Assy 9373729211
361 Accum Support Assy 9372252017
Ref.
No.
Description
Ord.
Q'ty
Part No.
109 Terminal Cover (Comp) 9373264019
187 Clip (Cable) 9352715006
199 Br Sheet 9363708042
218-3 Relay 9900117016
260 Receiver Tank Assy 9373426011
349 Capirarry Assy 9373729211
345 Joint Pipe (3Way) Assy 9373729129
346 Expansion Valve Assy 9373729068
347 Discharge Pipe Assy not available
348 Pressur Switch Assy 9373729044
273 Strainer Assy 9366602019
335 Accumlator Holder Rubber 9354022010
343 Solenoid 9900165079
344 4-Way Valve 9900163013
334 Accumlator 9368391003
14 Valve Cover 9372796016
13-3 3-Way Valve 9372205051
15 Condenser Sub Assy 9372313121
20
2006.04.07
64 Side Panel L Ptd 9371926018
69-3 Bolt, hex, Socket 301210060360
85 Valve Plate Ptd 9371928036
108 Rubber Seat (Comp) 9358080009
55 Special Nut M8 9355091008
