Fujitsu ARYG30LMLE User Manual

INDOOR UNIT H x W x D
H x W x DOUTDOOR UNIT
DIMENSIONS
INDOOR UNIT Shipping / Net
Shipping / NetOUTDOOR UNIT
WEIGHT
POWER SOURCE
Cooling
RUNNING CURRENT
Heating
INPUT WATTS
Cooling
Heating
E.E.R.
C.O.P.
Cooling
Heating
Cooling
Heating
STARTING CURRENT
MOISTURE REMOVAL
AIRCIRCULATION OUTDOOR
FAN SPEED
Discrimination
High (heating)
INDOOR UNIT
Medium
Low
Speed
Discrimination
OUTDOOR
UNIT
TYPE
Cooling & Heating
INDOOR UNIT ARYG30LMLE
ARYG36LMLE
OUTDOOR UNIT AOYG30LETL AOYG36LETL
COOLING CAPACITY
HEATING CAPACITY
270 x 1,135 x 700 mm
830 x 900 x 330 mm
47 kg / 40 kg
68 kg / 61 kg
11.6 A
11.7 A
2.65 kW
2.68 kW
3.21 kW/kW
3.73 kW/kW
13.0 A
13.6 A
2.96 kW
3.10 kW
3.18 kW/kW
3.61 kW/kW
13.7 A
3.0 L/hr
3,800 m3/hr
12.2 A
MAXIMUM CURRENT
20.0 A
17.0 A
2.5 L/hr
3,600 m3/hr
AIRCIRCULATION
INDOOR
2,100 m3/hr2,100 m3/hr
1,900 m3/hr1,900 m3/hr
230 V 50 Hz 230 V 50 Hz
MFG-45RVN
1,270 r.p.m.
980 r.p.m.
790 r.p.m.
MFE-60TVT
850 r.p.m.
MFG-45RVN
1,270 r.p.m.
High (cooling) 1,130 r.p.m. 1,130 r.p.m.
980 r.p.m.
790 r.p.m.
Quiet 630 r.p.m. 630 r.p.m.
MFE-60TVT
900 r.p.m.
8.5 kW 9.4 kW
10.0 kW
11.2 kW
ELECTRICAL DATA
COMPRESSOR TYPE
DISCRIMINATION
WEIGHT (with oil)
PRECHARGED REFRIGERANT
REFRIGERANT TYPE
R410A
Hermetic type, Inverter,
6 poles, DC motor,
2-cylinder rotary
N-TF30ND1A
2,100 g
15.3 kg
COMPRESSOR AND REFRIGERANT
2013.02.27 1
SPECIFICATIONS
MAX PIPE LENGTH 50 m
MAX PIPE HEIGHT 30 m
Pipe length
20 m 2,100 g
FULL CHARGE
30 m
2,500 g
40 m 2,900 g
50 m
3,300 g
ADDITIONAL CHARGE 40 g/m
NOISE LEVEL
High (cooling) 39 dB
INDOOR UNIT
Medium 35 dB
Low
Cooling
Heating
30 dB
39 dB
High (heating) 42 dB 42 dB
35 dB
30 dB
Quiet
26 dB 26 dB
OUTDOOR
UNIT
53 dB 54 dB
55 dB 55 dB

Fujitsu ARYG30LMLE Specifications

General

Type	Air conditioner indoor unit
Ionizer	-
Multi-split	Yes
Product color	Gray
Refrigerating medium	R410A
Air conditioner functions	Cooling, Dehumidifying, Heating
Refrigerating medium weight	2100 g
Cooling capacity in watts (max)	10000 W
Cooling capacity in watts (min)	2800 W
Heating capacity in watts (max)	11200 W
Heating capacity in watts (min)	2700 W
Cooling capacity in watts (nominal)	8500 W
Cooling energy efficiency (EER, W/W)	3.21
Heating energy efficiency (COP, W/W)	3.73
Seasonal efficiency rating (cooling) (SEER)	5.9
Seasonal efficiency rating (heating) (SCOP)	3.9
Heating capacity in watts (nominal) (Colder heating season)	- W
Current	20 A
AC input voltage	230 V
Current (cooling)	17 A
AC input frequency	50 Hz
Design load (cooling)	8.5 kW
Energy efficiency class (cooling)	A+
Annual energy consumption (cooling)	504 kWh
Design load (heating) (Warmer heating season)	- kW
Design load (heating) (Average heating season)	10 kW
Energy efficiency class (heating) (Average heating season)	A
Annual energy consumption (heating) (Warmer heating season)	- kWh
Annual energy consumption (heating) (Average heating season)	2868 kWh
Indoor unit type	Ducted
Indoor unit depth	700 mm
Indoor unit width	1135 mm
Indoor unit height	270 mm
Indoor unit weight	40000 g
Indoor units quantity	1
Cooling airflow (indoor unit)	1900 m³/h
Indoor unit sound power level	65 dB
Indoor unit noise level (low speed)	26 dB
Indoor unit noise level (high speed)	39 dB
Wi-Fi	No
Outdoor unit noise level	- dB
