Fujitsu ARYG90LHTA - SPECIFICATIONS; ELECTRICAL DATA; FAN REVOLUTION; AIR CIRCULATION

2017.04.05
1
INDOOR UNIT ARYG90LHTA
OUTDOOR UNIT AOYG90LRLA
Capacity 22.00 kW
Capacity 27.00 kW
POWER SUPPLY Outdoor Three phase 400V 50Hz
POWER SUPPLY Indoor Single phase 230V 50Hz
Rated operating current Outdoor
13.5 A
Rated operating current Indoor
Rated operating current Outdoor
Rated operating current Indoor
3.5 A
Max operating current Outdoor
14.6 A
Max operating current Indoor
Max operating current Outdoor
Max operating current Indoor
6.0 A
14.6 A
6.0 A
14.1 A
3.5 A
Power consumption
Power consumption
COOLING
7.77 kW
HEATING
8.18 kW
EER
COP
2.83 kW/kW
3.30 kW/kW
Moisture removal 6.0 L/h
COMPRESSOR TYPE
Scroll type,
3 pole, 3 phase,
DC brushless motor
DISCRIMINATION
WEIGHT (with oil)
ANB66FVFMT
REFRIGERANT TYPE
PRECHARGED REFRIGERANT
R410A
7,100 g
37.6 kg
MFG-ZK1KA2N
INDOOR UNIT
FAN MOTOR DISCRIMINATION
AIR CIRCULATION
MFE-ZA2VB2NOUTDOOR UNIT
INDOOR UNIT
OUTDOOR UNIT
3,900 m
3
/h
3,450 m
3
/h
3,000 m
3
/h
8,400 m
3
/h
9,000 m
3
/h
4,300 m
3
/h
MAX PIPE HEIGHT 30 m
High 1,210 rpm
INDOOR UNIT
Medium 1,100 rpm
FAN REVOLUTION
Quiet
880 rpm
Low 990 rpm
Heating
OUTDOOR UNIT
Upper 780 / Lower 740
Cooling
Upper 730 / Lower 690
DIMENSIONS
INDOOR UNIT 360 x 1,400 x 850 mm
H x W x D
H x W x D
OUTDOOR UNIT 1,428 x 1,080 x 480 mm
WEIGHT
INDOOR UNIT
80 kg / 91 kg
Net / Shipping
Net / Shipping
OUTDOOR UNIT
174 kg / 192 kg
ELECTRICAL DATA
SPECIFICATIONS
COMPRESSOR AND REFRIGERANT
Pipe length
30 m 7,100 g
FULL CHARGE
50 m 9,300 g
70 m 11,500 g
100 m 14,800 g
ADDITIONAL CHARGE
110 g/m
NOISE LEVEL
High 47 dB
INDOOR UNIT
Medium 44 dB
Quiet
Cooling
Heating
40 dB
OUTDOOR UNIT
57 dB
55 dB
Low
High
Medium
Quiet
Cooling
Heating
Low
42 dB
Static pressure : 72Pa
Duct length : Inlet 1m, Outlet 2m
