Fujitsu AS G07KGTB Series Design & Technical Manual

Combination of indoor
unit
Rated capacity for each indoor unit
(kW)
Total capacity
(kW)
Input power (kW)
EER
(W/W)
Seasonal data
Room
Total
Room
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SEER
(kWh/kWh)
Energy effi-
ciency class
1 2 3 4 2 3 4
7 7 9 18 41 1.37 1.37 1.76 3.50 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 7 12 12 38 1.47 1.47 2.53 2.53 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 7 12 14 40 1.40 1.40 2.40 2.80 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 7 12 18 44 1.27 1.27 2.18 3.28 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 7 14 14 42 1.33 1.33 2.67 2.67 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 7 14 18 46 1.22 1.22 2.43 3.13 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 9 9 9 34 1.64 2.12 2.12 2.12 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 9 9 12 37 1.51 1.95 1.95 2.59 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 9 9 14 39 1.43 1.85 1.85 2.87 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 9 9 18 43 1.30 1.67 1.67 3.36 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 9 12 12 40 1.40 1.80 2.40 2.40 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 9 12 14 42 1.33 1.71 2.29 2.67 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 9 12 18 46 1.21 1.57 2.09 3.13 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 9 14 14 44 1.26 1.64 2.55 2.55 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 9 14 18 48 1.17 1.50 2.33 3.00 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 12 12 12 43 1.31 2.23 2.23 2.23 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 12 12 14 45 1.24 2.13 2.13 2.50 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 12 12 18 49 1.14 1.96 1.96 2.94 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
7 12 14 14 47 1.19 2.05 2.38 2.38 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
9 9 9 9 36 2.00 2.00 2.00 2.00 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
9 9 9 12 39 1.85 1.85 1.85 2.45 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
9 9 9 14 41 1.76 1.76 1.76 2.72 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
9 9 9 18 45 1.60 1.60 1.60 3.20 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
9 9 12 12 42 1.71 1.71 2.29 2.29 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
9 9 12 14 44 1.64 1.64 2.18 2.54 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
9 9 12 18 48 1.50 1.50 2.00 3.00 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
9 9 14 14 46 1.57 1.57 2.43 2.43 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
9 12 12 12 45 1.61 2.13 2.13 2.13 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
9 12 12 14 47 1.53 2.04 2.04 2.39 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
9 12 14 14 49 1.46 1.96 2.29 2.29 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
12 12 12 12 48 2.00 2.00 2.00 2.00 2.4 8.00 10.1 0.45 2.05 3.25 3.90 8.0 8.5 A+++
NOTES:
• 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h, 18: 18,000 Btu/h, 22: 22,000
Btu/h, 24: 24,000 Btu/h
• Values mentioned in the table are based on the following conditions:
– Power source of specifications: 230 V
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB.
• 2 or more indoor units should be connected.
• The total ability of connected a indoor unit is from 25,000 Btu up to 49,000 Btu.
- 391 -
6-1. Combinations
6. Capacity table
OUTDOOR UNIT AOYG30KBTA4
OUTDOOR UNIT
AOYG30KBTA4

Fujitsu AS G07KGTB Series Specifications
