Fujitsu AS G07KGTB Series Design & Technical Manual


Heating
Combination of indoor unit
Rated capacity for each indoor
unit (kW)
Total capacity
(kW)
Input power (kW)
COP
(W/W)
Seasonal data
Room
Total
Room
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SCOP
(kWh/
kWh)
Energy
efficien-
cy class
1 2 3 4 1 2 3 4
7 22 — — 29 2.40 7.20 — — 3.0 9.60 11.2 0.30 2.47 2.95 3.89 6.5 4.1 A+
7 24 — — 31 2.17 7.43 — — 3.0 9.60 11.2 0.30 2.47 2.95 3.89 6.5 4.1 A+
9 22 — — 31 2.79 6.81 — — 3.0 9.60 11.2 0.30 2.47 2.95 3.89 6.5 4.1 A+
9 24 — — 33 2.62 6.98 — — 3.0 9.60 11.2 0.30 2.47 2.95 3.89 6.5 4.1 A+
12 18 — — 30 3.84 5.76 — — 3.0 9.60 11.2 0.30 2.47 2.95 3.89 6.5 4.1 A+
12 22 — — 34 3.39 6.21 — — 3.0 9.60 11.2 0.30 2.47 2.95 3.89 6.5 4.1 A+
12 24 — — 36 3.20 6.40 — — 3.0 9.60 11.2 0.30 2.47 2.95 3.89 6.5 4.1 A+
14 18 — — 32 4.20 5.40 — — 3.0 9.60 11.2 0.30 2.47 2.95 3.89 6.5 4.1 A+
14 22 — — 36 3.73 5.87 — — 3.0 9.60 11.2 0.30 2.47 2.95 3.89 6.5 4.1 A+
14 24 — — 38 3.54 6.06 — — 3.0 9.60 11.2 0.30 2.47 2.95 3.89 6.5 4.1 A+
18 18 — — 36 4.80 4.80 — — 3.0 9.60 11.2 0.30 2.47 2.95 3.89 6.5 4.1 A+
18 22 — — 40 4.32 5.28 — — 3.0 9.60 11.2 0.30 2.47 2.95 3.89 6.5 4.1 A+
18 24 — — 42 4.11 5.49 — — 3.0 9.60 11.2 0.30 2.47 2.95 3.89 6.5 4.1 A+
22 22 — — 44 4.80 4.80 — — 3.0 9.60 11.2 0.30 2.47 2.95 3.89 6.5 4.1 A+
22 24 — — 46 4.59 5.01 — — 3.0 9.60 11.2 0.30 2.47 2.95 3.89 6.5 4.1 A+
24 24 — — 48 4.80 4.80 — — 3.0 9.60 11.2 0.30 2.47 2.95 3.89 6.5 4.1 A+
7 7 12 — 26 2.40 2.40 4.20 — 3.0 9.00 10.4 0.30 2.11 2.60 4.27 6.0 4.4 A+
7 7 14 — 28 2.40 2.40 4.80 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 7 18 — 32 2.10 2.10 5.40 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 7 22 — 36 1.87 1.87 5.86 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 7 24 — 38 1.77 1.77 6.06 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 9 9 — 25 2.40 3.00 3.00 — 3.0 8.40 10.0 0.30 1.94 2.45 4.32 6.0 4.4 A+
7 9 12 — 28 2.40 3.00 4.20 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 9 14 — 30 2.24 2.88 4.48 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 9 18 — 34 1.98 2.54 5.08 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 9 22 — 38 1.77 2.27 5.56 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 9 24 — 40 1.68 2.16 5.76 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 12 12 — 31 2.16 3.72 3.72 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 12 14 — 33 2.04 3.49 4.07 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 12 18 — 37 1.82 3.11 4.67 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 12 22 — 41 1.64 2.81 5.15 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 12 24 — 43 1.56 2.68 5.36 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 14 14 — 35 1.92 3.84 3.84 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 14 18 — 39 1.72 3.45 4.43 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 14 22 — 43 1.56 3.13 4.91 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 14 24 — 45 1.49 2.99 5.12 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 18 18 — 43 1.56 4.02 4.02 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 18 22 — 47 1.43 3.68 4.49 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 18 24 — 49 1.37 3.53 4.70 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
9 9 9 — 27 3.00 3.00 3.00 — 3.0 9.00 10.8 0.30 2.11 2.76 4.27 6.0 4.4 A+
9 9 12 — 30 2.88 2.88 3.84 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
9 9 14 — 32 2.70 2.70 4.20 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
9 9 18 — 36 2.40 2.40 4.80 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
9 9 22 — 40 2.16 2.16 5.28 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
9 9 24 — 42 2.06 2.06 5.48 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
9 12 12 — 33 2.62 3.49 3.49 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
9 12 14 — 35 2.47 3.29 3.84 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
9 12 18 — 39 2.22 2.95 4.43 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
9 12 22 — 43 2.01 2.68 4.91 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
9 12 24 — 45 1.92 2.56 5.12 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
9 14 14 — 37 2.34 3.63 3.63 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
9 14 18 — 41 2.11 3.28 4.21 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
9 14 22 — 45 1.92 2.99 4.69 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
9 14 24 — 47 1.84 2.86 4.90 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
9 18 18 — 45 1.92 3.84 3.84 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
12 12 12 — 36 3.20 3.20 3.20 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
12 12 14 — 38 3.03 3.03 3.54 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
12 12 18 — 42 2.74 2.74 4.12 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
12 12 22 — 46 2.50 2.50 4.60 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
12 12 24 — 48 2.40 2.40 4.80 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
12 14 14 — 40 2.88 3.36 3.36 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
12 14 18 — 44 2.62 3.05 3.93 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
12 18 18 — 48 2.40 3.60 3.60 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
14 14 14 — 42 3.20 3.20 3.20 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
14 14 18 — 46 2.92 2.92 3.76 — 3.0 9.60 11.2 0.30 2.27 2.95 4.22 6.5 4.3 A+
7 7 7 7 28 2.40 2.40 2.40 2.40 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 7 7 9 30 2.24 2.24 2.24 2.88 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 7 7 12 33 2.04 2.04 2.04 3.48 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 7 7 14 35 1.92 1.92 1.92 3.84 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 7 7 18 39 1.72 1.72 1.72 4.44 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 7 9 9 32 2.10 2.10 2.70 2.70 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 7 9 12 35 1.92 1.92 2.47 3.29 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 7 9 14 37 1.82 1.82 2.34 3.62 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 7 9 18 41 1.64 1.64 2.11 4.21 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 7 12 12 38 1.77 1.77 3.03 3.03 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 7 12 14 40 1.68 1.68 2.88 3.36 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 7 12 18 44 1.53 1.53 2.62 3.92 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 7 14 14 42 1.60 1.60 3.20 3.20 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 7 14 18 46 1.46 1.46 2.92 3.76 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 9 9 9 34 1.98 2.54 2.54 2.54 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 9 9 12 37 1.81 2.34 2.34 3.11 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 9 9 14 39 1.71 2.22 2.22 3.45 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 9 9 18 43 1.56 2.01 2.01 4.02 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 9 12 12 40 1.68 2.16 2.88 2.88 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 9 12 14 42 1.60 2.06 2.74 3.20 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 9 12 18 46 1.46 1.88 2.50 3.76 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
