Fujitsu ASAG09LJCA - Page 54

2
1
3
6
7
8
4
5
INDOOR UNIT
COMPACT WALL MOUNTED
ASYG07LUCA
ASYG09LUCA
ASYG12LUCA
2011.12.21 53
5
2
6
4
3
Under Cover 9318879001
1 Bracket Panel 9318913002
7
Wire Cover 9318911008
Wire Shield 9318919004
8 Remote Control Holder 9318912005
Remote Control 9319207018
Ref. Description Part number
Louver U (Upper) 9318880007
Louver Z (Lower) 9318881004
