Fujitsu AST12 SERIES User Manual

4
Fig. 5 Remote Control Unit
D SLEEP button
E MASTER CONTROL button
F SET TEMP./SET TIME buttons (
)
G Signal Transmitter
H TIMER button
I FAN CONTROL button
J START/STOP button
K AIR FLOW DIRECTION button
L SWING LOUVER button
M TIME ADJUST button
N ACL button
Rear side (Fig. 6)
O TEST RUN
● Touch the two metal contacts with a me-
tallic object to send the signal to perform
a test run.
● Perform a test run only when installing the
air conditioner. If the signal to perform a
test run is received during normal opera-
tion, the air conditioner’s thermostat will
malfunction.
● If the signal to perform a test run is re-
ceived during normal operation, the unit
will switch to the test operation mode and
the indoor unit’s OPERATION and TIMER
indicator lamps will flash simultaneously.
● To stop the test operation mode, press the
START/STOP button to stop the air condi-
tioner.
P Remote Control Unit Display (Fig. 7)
Q Transmit Indicator
R Clock Display
S Operating Mode Display
T T imer Mode Display
U Fan Speed Display
V Temperature Set Display
W T imer Set Indicator
X Temperature Set Indicator
Fig. 1 Indoor Unit
1 Operating Control Panel (Fig. 2)
2 MANUAL AUTO button
3 Remote Control Signal Receiver
4 Indicator Lamps (Fig. 3)
5 OPERATION Indicator Lamp (red)
●
Lights when unit is operating.
*
● The lamp will flash slowly when the de-
frosting operation (see page 17).
*
● The lamp will flash quickly (1 second on, 1
second off) when the selected operating
mode can not be used (see page 18).
6 TIMER Indicator Lamp (green)
●
If the TIMER indicator lamp flashes when
the timer is operating, it indicates that a
fault has occurred with the timer setting
(see page 17 Auto Restart).
7 SWING Indicator Lamp (orange)
8 Intake Grille (Fig. 4)
9 Air Filter
0 Air Flow Direction Louver
A Right-Left Louver
(behind Air Flow Direction Louver)
B Drain Hose
C Air Cleaning Filter
