ACTPM
Compressor
4-way valve
4-way valve
3-1 AOU18/ 24RLXFZ
3-1-1 PARTS LAYOUT DRAWING
03-01
Motor DC Brushless
Propeller Fan assy
Condenser A assy
Coil (Expansion valve)&
Expansion valve
Coil (Expansion valve)&
Expansion valve
Solenoid
Solenoid
Pressure SW
Choke Coil
Accumulator
Main PCB
Filter PCB
AOU24RLXFZ
AOU18RLXFZ
