OUTDOOR UNIT
23
29
21
29 Condenser A Assy
21 Separate Wall Sub Assy
9374433179
9374413164
23 Valve Plate Assy 9374628094
Ref. Description Part number
28
27
Connector : RED
Connector : WHITE
22
30
31
25
25
26
26
26
24
32
22 Choke Coil
30 Inlet Pipe (Cond) A Assy
31 Outlet Pipe (Cond) A Assy
32 Receiver Tank Assy
24
25
3-way Valve Assy (1/2")
26 2-way Valve Assy
9900366018
9373461104
9374266111
9374575039
3-way Valve Assy (3/8") 9375103019
9375104016
9375102012
27
28 Pipe Thermistor (Red)
Pipe Thermistor (White) 9900543020
-- Strainer Assy 9372524015
9900632007
To Next Page
