11 Crossflow Fan Assy
12 Bearing C Assy
Evaporator Total Assy14
Water Seal15
Evaporator Holder R16
Evaporator Holder L
Parts number
DescriptionRef
9315024015
9306628017
9315338129
9315251015
9314994012
17
Rear Bracket18
19
20
21
Filter Guide
Filter Guard
Connection Pipe Assy
9314995019
9315022011
9315013019
9315411013
9315355041
13 Room Thermistor Holder
23 Pipe Thermistor
9315252012
9900551018
22 Distributor Assy 9316988019
20
18
19
16
21
15
14
23
22
12
11
13
17
472010.06.30
INDOOR UNIT
WALL MOUTED
ASU18RLF
