The method of adjusting inter-unit wire harness
To connect inter-unit wire harness to the terminal correctly, please
refer to the figure to adjust the length of the part of Inter-unit Wire
harness ahead from conduit holder.
7-1/2" (190mm) 1" (25mm)
1" (25mm)
7" (175mm)
(1:1)
14AWG
EARTH WIRE
CONDUIT HOLDER
CONDUIT CONNECTOR
