OUTDOOR UNIT
AOU36RLXFZ1
DIMENSIONS
14-9/16 inch
370 mm
25-19/32 inch 650 mm
35-7/16 inch 900 mm
1-9/16 inch
40 mm
1-7/32 inch
31 mm
15/32 inch
12 mm
32-11/16 inch
830 mm
13/16 inch
21 mm
11/32 inch
9 mm
15-3/4 inch
400 mm
13 inch
330 mm
5
2015.03.02
