C202
660/
450V
R200
220K
<2W>
B
B
W13
VIOLET
W12
WHITE
+
C201
660/
450V
C200
660/
450V
+ +
POWER_G
B
B
N
P
W7
YELLOW
W8
BLUE
CAPACITOR PCB ASSY
K05DG-0500HUE-P0
OUTDOOR UNIT
122006.10.13
