WALL MOUNTED TYPE ASU30-36CLX1 WALL MOUNTED TYPE ASU30-36CLX1
MODEL

: ASU36CLX1
AFR 695
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
14 27.62 19.93 1.01 30.77 20.05 1.03 33.92 21.87 1.04 34.97 23.61 1.05 37.07 23.52 1.06 39.16 25.05 1.07
32 27.59 20.68 1.33 30.74 20.80 1.35 33.88 22.69 1.37 34.93 24.50 1.38 37.02 24.41 1.39 39.12 26.00 1.41
41 27.58 19.90 1.48 30.72 20.02 1.51 33.86 21.84 1.53 34.91 23.58 1.54 37.00 23.49 1.55 39.10 25.02 1.57
50 27.51 20.29 1.68 30.65 20.41 1.70 33.78 22.27 1.73 34.83 24.05 1.74 36.92 23.95 1.76 39.01 25.51 1.77
59 27.32 20.19 1.85 30.44 20.31 1.88 33.55 22.15 1.91 34.59 23.92 1.92 36.66 23.82 1.94 38.74 25.38 1.96
67 26.28 19.60 2.16 29.27 19.72 2.20 32.26 21.51 2.23 33.26 23.23 2.24 35.26 23.13 2.27 37.25 24.64 2.29
77 28.33 20.75 3.10 31.55 20.88 3.15 34.78 22.77 3.20 35.86 24.59 3.21 38.01 24.49 3.25 40.16 26.09 3.28
87 26.96 19.98 3.47 30.03 20.10 3.52 33.10 21.92 3.58 34.12 23.68 3.60 36.17 23.58 3.63 38.22 25.12 3.67
95 25.47 19.15 3.86 28.37 19.27 3.92 31.28 21.02 3.98 33.00 21.80 3.88 34.18 22.60 4.04 36.11 24.08 4.08
104 23.81 18.24 4.23 26.52 18.35 4.30 29.24 20.01 4.37 30.14 21.61 4.39 31.95 21.52 4.43 33.76 22.93 4.48
115 18.13 15.20 3.54 20.19 15.29 3.59 22.26 16.67 3.65 22.95 18.01 3.67 24.33 17.94 3.70 25.70 19.11 3.74
AFR: Air ow rate (CFM)
TC: Total capacity (kBTU)
SHC: Sensible heat capacity (kBTU)
IP: Input Power (kW)
AFR 19.7
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.7 19.4 21.7 22.8
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
-10.0 8.10 5.84 1.01 9.02 5.88 1.03 9.94 6.41 1.04 10.25 6.92 1.05 10.86 6.89 1.06 11.48 7.34 1.07
0.0 8.09 6.06 1.33 9.01 6.10 1.35 9.93 6.65 1.37 10.24 7.18 1.38 10.85 7.15 1.39 11.47 7.62 1.41
5.0 8.08 5.83 1.48 9.00 5.87 1.51 9.92 6.40 1.53 10.23 6.91 1.54 10.84 6.88 1.55 11.46 7.33 1.57
10.0 8.06 5.95 1.68 8.98 5.98 1.70 9.90 6.53 1.73 10.21 7.05 1.74 10.82 7.02 1.76 11.43 7.48 1.77
15.0 8.01 5.92 1.85 8.92 5.95 1.88 9.83 6.49 1.91 10.14 7.01 1.92 10.75 6.98 1.94 11.35 7.44 1.96
19.4 7.70 5.75 2.16 8.58 5.78 2.20 9.46 6.30 2.23 9.75 6.81 2.24 10.33 6.78 2.27 10.92 7.22 2.29
25.0 8.30 6.08 3.10 9.25 6.12 3.15 10.19 6.67 3.20 10.51 7.21 3.21 11.14 7.18 3.25 11.77 7.65 3.28
30.6 7.90 5.86 3.47 8.80 5.89 3.52 9.70 6.43 3.58 10.00 6.94 3.60 10.60 6.91 3.63 11.20 7.36 3.67
35.0 7.47 5.61 3.86 8.32 5.65 3.92 9.17 6.16 3.98 9.70 6.39 3.88 10.02 6.62 4.04 10.58 7.06 4.08
40.0 6.98 5.35 4.23 7.77 5.38 4.30 8.57 5.87 4.37 8.83 6.33 4.39 9.36 6.31 4.43 9.89 6.72 4.48
46.1 5.31 4.45 3.54 5.92 4.48 3.59 6.52 4.89 3.65 6.73 5.28 3.67 7.13 5.26 3.70 7.53 5.60 3.74
AFR : Air ow rate (m
3
/min)
TC : Total capacity (kW)
SHC : Sensible heat capacity (kW)
IP: Input Power (kW)
