WALL MOUNTED TYPE ASU30-36CLX1 WALL MOUNTED TYPE ASU30-36CLX1
SPECIFICATIONS3.
Note :
Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F (26.67 °C)DB / 67°F (19.44 °C)WB, and outdoor temperature of 95°F (35 °C)DB / 75°F (23.9 °C)WB.
Pipe length : 24ft.7in. (7.5 m), Height difference : 0 m.(Outdoor unit - Indoor unit)
Type
WALL MOUNTED
INVERTER COOLING ONLY
Model name ASU30CLX1 ASU36CLX1
Power source 208/230V ~ 60Hz
Available voltage range 187-253V ~ 60Hz
Capacity
Cooling
Rated
kW 9.00 9.70
BTU/h 30,800 33,000
Min-Max
kW 2.90 - 9.50 2.90 - 10.00
BTU/h 9900 - 32400 9900 - 34100
Heating
Rated
kW - -
BTU/h - -
Min-Max
kW - -
BTU/h - -
Input power
Cooling
Rated
kW
3.24 3.88
Max 3.87 4.10
Heating
Rated - -
Max - -
Current
Cooling
Rated
A
14.2 17.0
Max 17.0 18.0
Heating
Rated - -
Max - -
EER Cooling
kW/kW 2.78 2.50
BTU/hW 9.5 8.5
COP Heating
kW/kW - -
BTU/hW - -
SEER Cooling BTU/hW 16.5 15.5
HSPF Heating BTU/hW - -
SENSIBLE CAPACITY Cooling kW 6.25 6.39
POWER FACTOR
Cooling
%
99 99
Heating - -
Moisture removal pints/h (l/h) 9.7(4.6) 10.1(4. 8)
Fan
Airow
rate
Cooling
High
CFM
(m
3
/h)
659 (1,120) 694 (1,180)
Med 530 (900) 530 (900)
Low 435 (740) 435 (740)
Quiet 365 (620) 365 (620)
Heating
High - -
Med - -
Low - -
Quiet - -
Type × Q'ty Cross ow fan x 1
Motor output W 42 65
Sound pressure level
Cooling
High
dB(A)
49 50
Med 42 42
Low 37 37
Quiet 33 33
Heating
High - -
Med - -
Low - -
Quiet - -
Heat exchanger type
Dimensions
(H × W × D)
in. (mm)
Main:15-7/8 x 33-3/4 x 1-1/16 (378×832×26.6)
Sub: 3-5/16 x 33-3/4 x 17/32 (84×832×13.3)
Fin pitch FPI Main:21, Sub:18
Rows x Stages Main:2×18, Sub:1×4
Pipe type Copper
Fin type Aluminium
Enclosure
Material Polystyrene
Color
White
Approximate Color of MUNSELL N9.25/
Dimensions
( H×W×D)
Net
mm 320×998×228
inch 12-5/8×39-1/4×9
Gross
mm 319×1090×429
inch 12-3/5×42-15/16×16-7/8
Weight
Net
lbs.(kg)
31 (14 )
Gross 40 (18 )
Connection pipe
Size
Liquid
in. (mm)
Ø3/8 (Ø9.52)
Gas Ø5/8 (Ø15.88 )
Method Flare
Operation range
Cooling
°F (°C) 64 to 90 (18 to 32)
%RH 80 or less
Heating °F (°C) - -
Remote controller type Wireless
Drain pipe
Material PVC
Size
mm
(Reference in.)
Outer diameter: 28 (1-3/32)
Inner diameter: 16 (5/8) .
