- (01 - 20) -
WALL MOUNTED TYPE
ASU30-36CLX1
WALL MOUNTED TYPE
ASU30-36CLX1
JUMPER WIRE SETTING
Auto restart setting (JM5)
z
.
(
Factory setting)
JM 5 Auto restart
Connect Validity
Disconnect Invalidity
Room temperature correction setting (JM6, JM7)
z
(
Factory setting)
JM 6 JM 7
Room temperature correction
Cooling Drying
Connect Connect Standard
Disconnect Connect Slightly lower control
Connect Disconnect Slightly lower control
Disconnect Disconnect Lower control
Remote controller signal code setting (JM8, JM10)
z
(
Factory setting)
Jumper wire
Remote controller
signal code
JM 8 JM 10
Connect Connect A
Disconnect Connect B
Connect Disconnect C
Disconnect Disconnect D
REMOTE CONTROLLER SIGNAL CODE SETTING
Use the following steps to select the signal code of the remote controller.
(Note that the air conditioner cannot receive a signal code if the air conditioner has not been set for the signal code.)
Press the START/STOP button until only the clock is displayed on the remote controller display.1.
Press the MODE button for at least ve seconds to display the current signal code (initially set to 2.
).
Press the SET TEMP. (3.
) ( ) button to change the signal code between → → → .
Match the code on the display to the air conditioner signal code.
Press the MODE button again to return to the clock display. The signal code will be changed.4.
If no buttons are pressed within 30 seconds after the signal code is displayed, the system returns to the original clock
display. In this case, start again from step 1.
The air conditioner signal code is set to A prior to shipment. Contact your retailer to change the signal code.
The remote controller resets to signal code A when the batteries in the remote controller are replaced. If you use a
signal code other than signal code A, reset the signal code after replacing the batteries.
If you do not know the air conditioner signal code setting,try each of the signal codes (
→ → → .) until you
nd the code which operates the air conditioner.
