D I M E N S I O N S
Models : ASU9RL / AOU9RL
ASU12RL / AOU12RL
02-01
Unit : Inch(mm)
INDOOR UNIT
OUTDOOR UNIT
10-1/4(260)
21-1/4(540)
7-25/32
(198)
31-3/32(790)
25-31/32(660)
11-13/32(290)
