43
44
42
41
46
47
45
INDOOR UNIT
Control box
2009.01.26
14
47
Display PCB Assy
9707649017
46
Display Case
9316587007
45
Controller PCB Assy (09)
9707645385
45
Controller PCB Assy (12)
9707645392
--
Earth Terminal
9316586000
--
Terminal
9900529017
41
Control Box
9316582019
42
Box Shield
9316580008
43
Control Cover
9316583016
44
Cover Shield
9316581005
Ref.
Description
Part number
14
16
Table of Contents
Table of Contents
1
Wall Mounted Type
1
Specifications
2
Dimensions
3
Refrigerant System Diagram
4
Circuit Diagram
5
Indoor Pcb Circuit Diagram
6
Outdoor Pcb Circuit Diagram
9
Error Detection
11
PARTS (Indoor Unit)
12
PARTS (Outdoor Unit)
16
Accessories
20
