Fujitsu ASU9RLF1 Technical Manual

- (02 - 01) -
OUTDOOR UNIT AOU9-12RLFW1 OUTDOOR UNIT AOU9-12RLFW1
SPECIFICATIONS1.
Type INVERTER HEAT PUMP
Model name AOU9RLFW1 AOU12RLFW1
Power sourse 208/230V~60HZ
Available voltage range 187-253V~60HZ
Starting current A 4.2 5.9
Fan
Airow rate
Cooling
CFM
(m
3
/h)
995(1690) 1036(1760)
Heating 906(1540) 889(1510)
Type×Q'ty Propeller fan×1
Motor output W 23 37
Sound pressure level
Cooling
dB(A)
48 49
Heating 48 49
Heat exchanger type
Dimensions
(H×W×D)
in. 19-13/16×25-1/4×1-7/16 19-13/16×35-1/4×1-7/16
mm 504×642×36.4 504×896×36.4
Fin pitch FPI 18
Rows×Stages 2×24
Pipe type Copper
Fin Type Aluminum
Compressor
Type×Q'ty Rotary×1
Motor output W 500 750
Refrigerant
Type R410A
Charge
lb.oz. 1lb.14oz. 2lb.5oz.
kg 0.85 1.05
Refrigerant oil Type RB68 VG74
Enclosure
Material Steel
Color
Beige
Approximate color of MUNSELL 10YR7.5/1.0
Dimensions
(H×W×D)
Net
mm 540×660×290 540×790×290
in. 21-1/4×26×11-7/16 21-1/4×31-1/8×11-7/16
Gross
mm 611×797×401 648×934×400
in. 24-1/16×31-3/8×15-13/16 25-1/2×36-3/4×15-3/4
Weight
Net
lb.(kg)
60(27) 80(36)
Gross 67(30) 86(39)
Connenction
pipe
Size
Liquid
in.
(mm)
Ø1/4(Ø6.35)
Gas Ø3/8(Ø9.52)
Method Flare
Pre - charge length
ft.
(m)
49(15)
Min. length 9(3)
Max.length 66(20)
Max.height difference 49(15)
Operation range
Cooling
°F
(°C)
14to115(-10 to 46)
Heating 5 to 75(-15to 24)
Note:
Specications are based on the following conditions.
Cooling:Indoor temperature of 80°F(26.67°C)DB/67°F(19.44°C)WB,and outdoor temperature of 95°F(35°C)DB/75°F(23.9°C)WB.
Heating:Indoor temperature of 70°F(21.11°C)DB/59°F(15°C)WB,and outdoor temperature of 47°F(8.33°C)DB/43°F(6.11°C)WB.
Pipe length:24ft.(7.5m),Height difference:0ft. (0m)(Outdoor unit-Indoor unit)
