WALL MOUNTED TYPE ASU9-12RLF1 WALL MOUNTED TYPE ASU9-12RLF1
SPECIFICATIONS3.
Type
WALL MOUNTED
INVERTER HEAT PUMP
Model name ASU9RLF1 ASU12RLF1
Power source 208/230V~60HZ
Available voltage range 187-253V~60HZ
Capacity
Cooling
Rated
kW 2.637 3.516
BTU/h 9000 12000
Min-Max
kW 0.50-3.20 0.90-3.90
BTU/h 1700-10900 3100-13300
Heating
Rated
kW 3.516 4.689
BTU/h 12000 16000
Min-Max
kW 0.50-4.40 0.90-5.60
BTU/h 1700-15000 3100-19100
Input power
Cooling
Rated
kW
0.65 0.96
Min - Max 0.25 - 1.27 0.25 - 1.40
Heating
Rated 0.89 1.28
Min - Max 0.25 - 1.60 0.25 - 1.99
Current
Cooling
Rated A
3.2 4.4
Heating 4.2 5.9
EER Cooling
kW/kW 4.05 3.66
BTU/hW 13.8 12.5
COP Heating
kW/kW 3.95 3.66
BTU/hW 13.50 12.50
SEER Cooling BTU/hW 23.0 22.0
HSPF Heating BTU/hW 11.0 11.0
POWER FACTOR
Cooling
%
88 95
Heating 92 94
Moisture removal pints/h(l/h) 2.75(1.3) 3.80(1.8)
Maximum operating current *
Cooling
A
6.0 6.5
Heating 7.5 9.0
Fan
Airow rate
Cooling
High
CFM
(m
3
/h)
441(750)
Med 376(640)
Low 282(480)
Quiet 182(310)
Heating
High 441(750)
Med 376(640)
Low 306(520)
Quiet 194(330)
Type×Q' t y Cross ow fan×1
Motor output W 30
Sound pressure level
Cooling
High
dB(A)
43 43
Med 40 40
Low 32 32
Quiet 21 21
Heating
High 43 43
Med 38 38
Low 33 33
Quiet 22 22
Heat exchanger type
Dimensions
(H×W×D)
in.(mm)
Main: 12-5/8 x 24-13/16 x 13/16 (320×630×20)
Sub: 3-5/16 x 24-13/16 x 1/2 (84×630×13.3)
Fin pitch FPI Main:23 Sub:18
Rows×Stages Main:2×20 Sub:1×4
Pipe type Copper
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
Approximate color of MUNSELL N9.25/
Dimensions
(H×W×D)
Net
mm 268 x 840 x 203
in. 10-9/16 x 33-1/16 x 8
Gross
mm 270 x 884 x 336
in. 10-5/8 x 34-13/16 x 13-1/4
Weight
Net
lb.(kg)
19(8.5)
Gross 24(10.5)
Connection pipe
Size
Liquid
in.(mm)
Ø1/4(Ø6.35)
Gas Ø3/8(Ø9.52)
Method Flare
Operation range
Cooling
°F(°C) 64 to 90(18 to 32)
%RH 80 or less
Heating °F(°C) 88(30) or less
Remote controller type Wireless
Drain pipe
Material PP + LLDPE
Size
mm
(Reference in.)
Ø 9/16 (13.8) (I.D.)
Ø5/8 to Ø11/16 (15.8 to 16.7) (O.D.)
Note:
●Specications are based on the following conditions.
Cooling:Indoor temperature of 80°F(26.67°C)DB/67°F(19.44°C)WB,and outdoor temperature of 95°F(35°C)DB/75°F(23.9°C)WB.
Heating:Indoor temperature of 70°F(21.11°C)DB/59°F(15°C)WB,and outdoor temperature of 47°F(8.33°C)DB/43°F(6.11°C)WB.
Pipe length:24ft.(7.5m),Height difference:0ft. (0m) (Outdoor unit-Indoor unit)
●The protective function might work when using it in environment out of the temperature range mentioned above.
*: The maximum current is the maximum value when operated within the operation range.
