Signal
transmitter
MIN. HEAT
button
TEMP.
button
POWERFUL
button
Start/Stop
button
MODE button
ECONOMY button
SWING button
TIMER ON button
TIMER OFF button
TIMER SELECT button
TIMER SLEEP button
TIMER CANCEL button
SET button
FAN button
RESET button
°C / °F switching button
CLOCK ADJUST button
Display panel
To facilitate explanation, the accompanying illustration has been drawn to show all possible indicators; in actual operation,
however, the display will only show those indicators appropriate to the current operation.
Mode indicator
Clock & Timer
indicator
Send indicator
Temperature indicator
Transmit indicator
Fan Speed indicator
Swing indicator
SPECIFICATION
NOTE: Some button operations may
not be available for all units
or systems.
For details, refer to the
operation manual.
DIMENSIONS [H × W × D]: in. (mm) 8-1/16 (205) × 2-3/8 (61) × 11/16 (17)
WEIGHT oz. (g) 4.3 (122)
ACCESSORY Holder
