Fujitsu ASU9RLS2 - Indoor Unit Heating Capacity Data

PARTS
2
1
3
6
8
9
7
4
5
INDOOR UNIT
2011.12.28 13
5
2
6
4
3
Under Cover 9318879001
1 Bracket Panel 9318913002
8
Wire Cover 9318911008
9
Wire Shield 9318919004
7 Air Clean Filter Assy 9317250009
Remote Control 9319634005
Remote Control Holder 9318912005
Ref. Description Part number
Louver (Upper) 9318880007
Louver (Lower) 9318881004
