Fujitsu ASU9RLS3 User Manual

- (01 - 13) -
WALL MOUNTED TYPE ASU9-15RLS3 WALL MOUNTED TYPE ASU9-15RLS3
HEATING CAPACITY6-2.
MODEL

: ASU9RLS3
AFR : Air Flow Rate (CFM)
TC : Total Capacity (kBtu/h)
IP : Input Power (kW)
AFR : Air Flow Rate (m
3
/min)
TC : Total Capacity (kW)
IP : Input Power (kW)
MODEL

: ASU12RLS3
AFR : Air Flow Rate (CFM)
TC : Total Capacity (kBtu/h)
IP : Input Power (kW)
AFR : Air Flow Rate (m
3
/min)
TC : Total Capacity (kW)
IP : Input Power (kW)
AFR 487
Indoor temperature
°FDB 60 65 70 75
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP
-15 -17 11. 6 2.15 11.4 2.19 11.1 2.23 10.5 2.31
-5 -7 14.7 2.16 14.3 2.20 14.0 2.24 13.3 2.32
5 3 16.1 2.17 15.7 2.21 15.4 2.25 14.6 2.34
14 12 16.8 2.13 16.4 2.17 16.0 2.22 15.2 2.30
23 19 18.3 2.10 17.9 2.14 17.5 2.18 16.6 2.26
32 28 18.8 2.06 18.4 2.10 17.9 2.14 17.0 2.22
41 37 21.3 1.88 20.8 1.92 20.3 1.95 19.3 2.03
47 43 23.1 1.85 22.6 1.89 22.0 1.93 20.9 2.01
50 47 25.5 1.84 24.9 1.88 24.3 1.91 23.1 1.99
59 50 26.5 1.63 25.8 1.67 25.2 1.70 23.9 1.77
AFR 13.8
Indoor temperature
°CDB 15.6 18.3 21.1 23.9
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP
-26.1 -27.0 3.41 2.15 3.33 2.19 3.25 2.23 3.09 2.31
-20.6 -21.7 4.31 2.16 4.20 2.20 4.10 2.24 3.90 2.32
-15.0 -16.1 4.73 2.17 4.61 2.21 4.50 2.25 4.28 2.34
-10.0 -11.1 4.91 2.13 4.80 2.17 4.68 2.22 4.45 2.30
-5.0 -7.2 5.38 2.10 5.25 2.14 5.12 2.18 4.86 2.26
0.0 -2.2 5.52 2.06 5.39 2.10 5.26 2.14 5.00 2.22
5.0 2.8 6.25 1.88 6.10 1.92 5.95 1.95 5.65 2.03
8.3 6 .1 6.77 1.85 6.61 1.89 6.45 1.93 6.13 2.01
10.0 8.3 7.48 1.84 7.30 1.88 7.13 1.91 6.77 1.99
15.0 10.0 7.75 1.63 7.57 1.67 7.38 1.70 7.02 1.77
AFR 13.8
Indoor temperature
°CDB 15.6 18.3 21.1 23.9
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP
-26.1 -27.0 3.62 2.15 3.54 2.19 3.45 2.23 3.28 2.31
-20.6 -21.7 4.63 2.16 4.52 2.20 4.41 2.24 4.19 2.32
-15.0 -16.1 5.11 2.17 4.99 2.21 4.86 2.25 4.62 2.34
-10.0 -11.1 5.36 2.13 5.23 2.18 5.10 2.22 4.85 2.30
-5.0 -7.2 5.86 2.10 5.72 2.14 5.58 2.18 5.30 2.26
0.0 -2.2 6.03 2.07 5.88 2.11 5.74 2.15 5.45 2.23
5.0 2.8 6.58 1.88 6.43 1.92 6.27 1.96 5.96 2.04
8.3 6 .1 6.80 1.86 6.64 1.90 6.48 1.94 6.15 2.02
10.0 8.3 7.52 1.85 7.34 1.89 7.16 1.93 6.80 2.00
15.0 10.0 7.79 1.64 7.60 1.68 7.42 1.71 7.05 1.78
AFR 487
Indoor temperature
°FDB 60 65 70 75
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP
-15 -17 12.4 2.15 12.1 2.19 11.8 2.23 11.2 2.31
-5 -7 15.8 2.16 15.4 2.20 15.0 2.24 14.3 2.32
5 3 17.4 2.17 17.0 2.21 16.6 2.25 15.8 2.34
14 12 18.3 2.13 17.8 2.18 17.4 2.22 16.5 2.30
23 19 20.0 2.10 19.5 2.14 19.0 2.18 18.1 2.26
32 28 20.6 2.07 20.1 2.11 19.6 2.15 18.6 2.23
41 37 22.5 1.88 21.9 1.92 21.4 1.96 20.3 2.04
47 43 23.2 1.86 22.7 1.90 22.1 1.94 21.0 2.02
50 47 25.6 1.85 25.0 1.89 24.4 1.93 23.2 2.00
59 50 26.6 1.64 25.9 1.68 25.3 1.71 24.0 1.78
