Display panel
2
4
9
3
1
16
15
5
17
18
19
21
24
23
22
25
10
FUNCTIONS
1
MODE button
Selects the operating mode (AUTO, HEAT, FAN, COOL, DRY).
/Start / end R.C. custom code change. (Max 4 types)
4
Filter reset button
5
Sleep button
Pressed to select sleep timer.
6
Fan button
Selects the fan speed (AUTO, QUIET, LOW, MED, HIGH).
7
START/STOP button
Pressed to start and stop operation.
8
Set button (Vertical)
Air flow direction vertical set button.
9
Set button (Horizontal)*
Air flow direction horizontal set button.
18
Economy display
20
Sleep display
21
Transmit indicator
22
Fan speed display
23
Swing display
24
Timer mode display
25
Clock display
Operating mode display
19
17
Temperature set display
2
Economy button
3
Set temp. button ( / )
Set remote controller custom code buttons
Sets the indoor temp./ Sets R.C. custom code.
Swing button
Air flow direction swing button.
10
12
Timer set ( / ) button
Sets the current time and on-off time.
11
Timer mode button
Pressed to select the timer mode. (OFF TIMER, ON TIMER,
PROGRAM TIMER, TIMER CANCEL)
Test run button
Used when testing the air conditioner after installation.
15
Signal transmitter
16
14
Reset button
Used when replacing batteries.
13
Clock adjust button
Sets the current time.
13
11
12
14
8
7
6
20
* These functions are not available.
SPECIFICATION
SIZE [H x W x D in. (mm)] 6-11/16 x 2-7/32 x 3/4 (170 x 56 x 19)
WEIGHT oz. ( g ) 3 (85) w/o batteries
ACCESSORY Holder
