Fujitsu ASU9RMLQ User Manual

-
(
01 - 15
)
-
MULTI TYPE 3-4ROOMS TYPE MULTI TYPE 3-4ROOMS TYPE
4-1. WALL MOUNTED TYPE
MODEL : ASU9R, ASU12R, ASU18R
Side view
INSTALLATION PLACE
Front view
4. DIMENSIONS
[Unit : Inch (mm)]
[Unit : Inch (mm)]
1-31/32 (50)
or over
Wall hook bracket
3-17/32 (90)
or over
(Wall cap)
96 (2400)
or over
59-1/16 (1500)
or over
2-3/8 (60)
or over
14-7/8
(378)
8-1/32
(204)
9-31/32
(253)
9-7/16
(240)
3-31/32
(101)
7/16
(11)
5-15/16
(151)
8-11/16
(221)
9-1/2
(241)
Wall hook
brackel
7-17/32
(191)
10-15/16
(278)
13-1/2
(343)
12-17/32
(318)
6-3/16 x 3/4 (hole)
(5 x 19 (hole))
for bolt
6-31/32 x 3/16 (hole)
(25 x 5 (hole))
for bolt
60-ø3/16 (5) (hole)
for tapping screw
ø3-5/32 (80) or more
for pipe inlet
ø3-5/32 (80) or more
for pipe inlet
16-7/32
(412)
4-3/4
(121)
6-23/32
(171)
10-5/8
(270)
10-13/16
(275)
8-15/16
(227)
9-3/16 x 15/16 (hole)
(5 x 24(hole))
for bolt
9-1/16
(230)
31-3/32
(790)
11-5/32
(283)

Fujitsu ASU9RMLQ Specifications

General

Brand	Fujitsu
Model	ASU9RMLQ
Category	Air Conditioner
Language	English
