Fujitsu ASU9RMLQ - INSTALLATION PLACE; 3-WAY DIRECTIONS SETTINGS

-
(
01 - 21
)
-
MULTI TYPE 3-4ROOMS TYPE MULTI TYPE 3-4ROOMS TYPE
INSTALLATION PLACE
39-3/8 (1,000)
or more
Strong and durable ceiling
47-1/4 (1,200)
or more
94-1/2 (2,400)
~ 106-1/4 (2,700)
Obstruction
Floor
[Unit : Inch (mm)]
4 (100) or more
[Unit : Inch (mm)]
3-WAY DIRECTIONS SETTINGS
To set “3-way directions”, the air outlet shutter plate (UTR-YDZB) sold separately
must be installed and “outlet-direction” switched to “3-way” by remote controller.
