01 - 07
-
MULTI TYPE
3-4ROOMS TYPE
MULTI TYPE
3-4ROOMS TYPE
Display panel
FUNCTIONS
SPECIFICATION
SIZE [H x W x D in. (mm)] 4-23/32 x 4-23/32 x 43/64 (120 x 120 x 17)
WEIGHT oz.( g ) 5-5/8 (160)
CABLE LENGTH ft.( m )
POWER ( V )
33 (10)
12
Display
15
14
12
13
11
10
9
2
1
3
5
4
7
8
6
DAY OFF
DELETE SET
ENERGY
SAVE
SET BACK
DAY
CLOCK ADJUST
SU
MO
TU
WE
TH FR
SA
369
12 15 18 21
THERMO
SENSOR
AM
PM
F
17
16
1819 20
2122 2324 25
SU
MO
TU
WE
TH FR
SA
369
12 15 18 21
AM
PM
F
1
START/STOP button
Pressed to start and stop operation.
5
Energy save button
Turns the energy efficient mode on and off.
Operation lamp
Lights during operation and when the timer is on.
15
Set button
Sets the date, hour, minute and on-off time.
12
14
Vertical air flow direction and swing button*
Push for two seconds to change the swing mode
Master control button
Selects the operating mode(AUTO, HEAT, FAN, COOL, DRY).
3
4
Fan control button
Selects the fan speed (AUTO, LOW, MED, HIGH).
Central control display
19
Operation mode display
17
18
Fan speed display
Timer and clock display
16
Temperature display
20
Day (DAY OFF) button
8
Temporarily cancels of one day timer.
Horizontal air flow direction and swing button*
13
Push for two seconds to change the swing mode.
Stand by display
21
Indicates during defrosting operation.
Set time button
Pressed to set time.
10
Set Temperature button
2
Selects the setting temperature.
Set back button
9
Pressed to select the set back timer.
11
Delete button
The schedule of a weekly timer is deleted.
7
Timer mode (CLOCK ADJUST) button
Selects the timer mode (OFF TIMER, ON TIMER, WEEKLY TIMER)
Set the current time.
6
Thermo sensor button
Selects whether the room temperature is detected at the
indoor unit (remote sensor) or the remote controller.
Vertical swing display*
22
Horizontal swing display*
23
Energy save display
24
*These functions are not available for concealed ceiling type.
Thermo sensor display
25
