Item no. Part no. Part name Service part

1 9388158013 Bracket panel ♦

2 9387476002 Screw cover ♦

3 9313951047 Conduit holder ♦

4 9383729027 Wire cover B ♦

5 9387597035 Wire cover assy ♦

6 9383765056 WLAN adapter holder assy ♦

7 9387479010 U/D louver assy ♦

8 9332911008 Electric filter holder ♦

9 9323341036 Under cover L ♦

10 9317250009 Air clean filter assy ♦

11 9334126011 Remote controller ♦

12 9334098004 Remote controller holder ♦

13 9384977038 Front panel total assy ♦

14 9387756210 Intake grille assy ♦

15 9323340008 Air filter ♦

16 9333719009 Grille clamper L ♦

17 9333704005 Grille clamper R ♦

18 9323342033 Under cover R ♦

19 9383730030 Louver spring ♦

20 9333608006 Bush ♦

— 9901010071

Wire with connector

(CN75 on main PCB—WLAN adapter)

♦

a — Front panel —

b — Panel cover —

c — Front panel B —

2-1. Models: ASUH18LPAS and ASUH24LPAS - (02-3) - 2. Indoor unit parts list
