7-12. Unit status monitoring and the detected value indication
The wired remote controller can monitor the indoor and outdoor units' status and display the detect-
ed result as a relevant ID.
For details of the display method, refer to the Chapter of “Display Sensor Values” in the Installation
Manual of Wired Remote Controller (Touch Panel).
The status can be monitored and displayed on the wired remote controller by assigning an arbitrary
ID. For available ID list, refer to the table below.
NOTE:
Operating time for each part cannot be reset when the part is replaced. Take notes of the
operating time before replacing to count the operating time of the replaced part.
Available Sensor ID
Sensor ID Item Unit Remarks
00: Indoor unit
00 000 Suction temp. 01: °F or °C
00 001 Room temp. 01: °F or °C
When the wired remote controller
thermistor is enabled, temperature of
the wired remote controller thermistor
is displayed.
00 002
Wired remote controller detected
temp.
01: °F or °C
00 006 Heat exchanger middle temp. 01: °F or °C
00 020 Fan rotation number 03: rpm
00 080 Indoor unit total energized hours 11: h
00 081 Total filtering hours 11: h
00 082 Indoor unit fan total operation hours 11: h
00 095
Presence or absence detected by
human sensor
00: —
0: Absence, 1: Presence
—: Human sensor error or No human
sensor
00 140 Operation or Stop (External input) 00: —
0: Off, 1: On
—: When the function setting 46 is
not set
NOTE: Available only for external
input port of the indoor unit
00 142 Forced stop (External input) 00: —
0: Off, 1: On
—: When the function setting 46 is
not set
NOTE: Available only for external
input port of the indoor unit
00 143 Operation or Stop 2 (External input) 00: —
0: Off, 1: On
—: When the function setting 46 is
not set
NOTE: Available only for external
input port of the indoor unit
00 155
Operation or Stop On/Off (External
output)
00: —
0: Off, 1: On
NOTE: The value is output even if
the function setting or
rotary switch is not set.
00 156 Error On/Off (External output) 00: —
0: Off, 1: On
NOTE: The value is output even if
the function setting or
rotary switch is not set.
00 157
Indoor unit fan interlocking On/Off
(External output)
00: —
0: Off, 1: On
NOTE: The value is output even if
the function setting or
rotary switch is not set.
7-12. Unit status monitoring and the detected value indication
- (04-27) - 7. Various control
CONTROL AND FUNCTIONS CONTROL AND FUNCTIONS
