Item no. Part no. Part name Service part

9383735165 Evaporator total assy (for 18 model) ♦

9383735189 Evaporator total assy (for 24 model) ♦

51 9387467000 Room thermistor holder ♦

52 9901013010 Terminal ♦

9711732064 Main PCB (for 18 model) ♦

9711732071 Main PCB (for 24 model) ♦

54 9900627041 Thermistor assy ♦

55 9711146052 Display assy ♦

56 9711147011 Indicator PCB ♦

57 9387589054 Motor case assy ♦

58 9603821005 Brushless motor ♦

59 9383565007 Pipe bracket ♦

60 9387488043 Cable guide ♦

61 9387714012 Gear case assy ♦

62 9901011016 Stepping motor ♦

63 9383728006 R and L louver SPM assy ♦

64 9901011023 Stepping motor ♦

65 9387590142 Drain pan total assy ♦

66 9316904002 Drain hose assy ♦

67 9316177017 Drain cap ♦

68 9333628004 Bearing D assy ♦

69 9387055054 Crossflow fan assy ♦

70 9387587173 Base assy ♦

a — Control box —

b — Control cover —

c — Display case —

d — Motor case —

e — Motor cover assy —

2-1. Models: ASUH18LPAS and ASUH24LPAS - (02-5) - 2. Indoor unit parts list
