Fujitsu ASUH36LPAS User Manual

¢
Model: ASUH36LPAS
AFR CFM 812
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kBtu kW kBtu kW kBtu kW kBtu kW kBtu kW kBtu kW
14 24.67 17.19 1.18 27.00 18.81 1.20 29.59 20.61 1.22 30.50 21.25 1.23 32.50 22.64 1.24 34.65 24.14 1.26
23 22.40 15.90 1.57 24.51 17.40 1.58 26.86 19.07 1.62 27.69 19.66 1.63 29.50 20.95 1.65 31.45 22.33 1.67
32 21.26 15.36 1.74 23.26 16.81 1.76 25.49 18.42 1.79 26.28 18.99 1.81 28.00 20.23 1.83 29.85 21.57 1.85
41 22.73 15.84 1.65 24.87 17.34 1.67 27.26 19.00 1.70 28.10 19.58 1.72 29.94 20.87 1.73 31.92 22.25 1.75
50 24.00 17.09 1.56 26.26 18.70 1.57 28.78 20.49 1.61 29.66 21.12 1.62 31.61 22.51 1.64 33.70 23.99 1.65
59 25.31 18.05 1.38 27.70 19.75 1.39 30.36 21.64 1.42 31.29 22.31 1.43 33.34 23.77 1.45 35.55 25.34 1.46
67 30.60 22.03 2.44 33.48 24.10 2.47 36.69 26.42 2.52 37.82 27.23 2.55 40.30 29.02 2.57 42.96 30.93 2.60
77 29.68 21.00 3.16 32.48 22.98 3.19 35.59 25.18 3.26 36.69 25.96 3.29 39.10 27.66 3.32 41.68 29.49 3.36
87 28.27 20.23 3.52 30.93 22.13 3.55 33.90 24.26 3.63 34.95 25.01 3.66 37.24 26.65 3.70 39.70 28.41 3.74
95 26.69 18.16 3.92 29.21 19.87 3.96 32.01 21.77 4.04 32.99 22.45 4.08 35.16 23.92 4.12 37.48 25.50 4.16
104 24.95 18.43 4.30 27.31 20.16 4.34 29.92 22.10 4.43 30.85 22.78 4.47 32.87 24.27 4.52 35.04 25.88 4.56
115 18.99 15.31 3.58 20.78 16.75 3.62 22.77 18.35 3.69 23.47 18.92 3.73 25.01 20.16 3.77 26.67 21.49 3.81
AFR
m
3
/h
1,380
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW
-10.0 7.23 5.04 1.18 7.91 5.51 1.20 8.67 6.04 1.22 8.94 6.23 1.23 9.53 6.64 1.24 10.15 7.07 1.26
-5.0 6.56 4.66 1.57 7.18 5.10 1.58 7.87 5.59 1.62 8.11 5.76 1.63 8.65 6.14 1.65 9.22 6.54 1.67
0.0 6.23 4.50 1.74 6.82 4.93 1.76 7.47 5.40 1.79 7.70 5.57 1.81 8.21 5.93 1.83 8.75 6.32 1.85
5.0 6.66 4.64 1.65 7.29 5.08 1.67 7.99 5.57 1.70 8.24 5.74 1.72 8.78 6.12 1.73 9.36 6.52 1.75
10.0 7.03 5.01 1.56 7.70 5.48 1.57 8.43 6.00 1.61 8.69 6.19 1.62 9.26 6.60 1.64 9.88 7.03 1.65
15.0 7.42 5.29 1.38 8.12 5.79 1.39 8.90 6.34 1.42 9.17 6.54 1.43 9.77 6.97 1.45 10.42 7.43 1.46
19.4 8.97 6.46 2.44 9.81 7.06 2.47 10.75 7.74 2.52 11.08 7.98 2.55 11.81 8.50 2.57 12.59 9.07 2.60
25.0 8.70 6.15 3.16 9.52 6.73 3.19 10.43 7.38 3.26 10.75 7.61 3.29 11.46 8.11 3.32 12.22 8.64 3.36
30.6 8.29 5.93 3.52 9.07 6.49 3.55 9.94 7.11 3.63 10.24 7.33 3.66 10.91 7.81 3.70 11.64 8.33 3.74
35.0 7.82 5.32 3.92 8.56 5.82 3.96 9.38 6.38 4.04 9.67 6.58 4.08 10.30 7.01 4.12 10.99 7.47 4.16
40.0 7.31 5.40 4.30 8.00 5.91 4.34 8.77 6.48 4.43 9.04 6.68 4.47 9.63 7.11 4.52 10.27 7.58 4.56
46.1 5.57 4.49 3.58 6.09 4.91 3.62 6.67 5.38 3.69 6.88 5.55 3.73 7.33 5.91 3.77 7.82 6.30 3.81
- 8 -
4-1. Cooling capacity
4. Capacity table
WALL MOUNTED ASUH30-36LPAS WALL MOUNTED ASUH30-36LPAS

Fujitsu ASUH36LPAS Specifications

General

Brand	Fujitsu
Model	ASUH36LPAS
Category	Air Conditioner
Language	English
