3. Installation space
3-1. Models: AOUH30LPAS1 and AOUH36LPAS1
¢
Space requirement
Provide sufficient installation space for product safety.
CAUTION
Keep the space shown in the installation examples.
If the installation is not performed accordingly, it could cause a short circuit and result in a lack of
operating performance.
 Single outdoor unit installation
• When the upper space is open:
Unit: in (mm)
When there are obstacles at the rear only. When there are obstacles at the rear and
sides.
4 (100) or more
10 (250)
or more
4 (100)
or more
4 (100)
or more
When there are obstacles at the front only. When there are obstacles at the front and
rear.
20 (500)
or more
20 (500)
or more
4 (100)
or more
- 64 -
3-1. Models: AOUH30LPAS1 and AOUH36LPAS1
3. Installation space
OUTDOOR UNIT AOUH30-36LPAS1 OUTDOOR UNIT AOUH30-36LPAS1
