– 2 –
HI-SPEED (dB)
C 39 - 39 C 39 - 39 C 40 - 40 C 40 - 40
H 38 - 38 H 39 - 39
MED-SPEED (dB)
C 38 - 38 C 38 - 38 C 39 - 39 C 39 - 39
INDOOR UNIT
H 35 - 35 H 35 - 35
LO-SPEED (dB)
C 36 - 36 C 36 - 36 C 37 - 37 C 37 - 37
H 31 - 31 H 30 - 30
QUIET (dB)
C 34 - 34 C 34 - 34 C 35 - 35 C 36 - 36
H 30 - 30 H 29 - 29
OUTDOOR UNIT (dB)
C 45 - 46 C 45 - 46 C 47 - 48 C 46 - 47
H 46 - 47 H 48 - 49
NOISE LEVEL
Note : Noise was measured in accordance with JIS standards, Japan.
Between 5 m and 10 m, when using a connection pipe other than that in the table, charge additional refrigerant with 20 g /1 m as the criteria.
ADDITIONAL REFRIGERANT CHARGE
Refrigerant suitable for a piping length of 5 m is charged in the outdoor unit at the factory.
When the piping is longer than 5 m, additional charging is necessary.
For the additional amount, see the table below.
PIPE LENGTH 5 m 10 m 15 m
ADDITIONAL REFRIGERANT None 100 g 200 g
WEIGHTS
INDOOR UNIT
GROSS / NET (kg)
10 / 8
OUTDOOR UNIT 33 / 30 35 / 32
