66
68
69
70
67
INDOOR UNIT
Motor base sub assy
2008.05.28 20
67 Step Motor 9900139049
68 Sector Gear 9368556006
69 Pinion Gear 9368557003
70 Flap Spring 9368612009
66 Motor Base 9368555009
Ref. Description
Part number
