2008.04.16 23
11 Motor Bracket Sub Assy
12 Propeller Fan Assy
13 Fan Motor
14 Condenser A Assy
15 Separate Wall Assy
16 Base Assy
17 Cap Foot
9374418053
9366378020
9601882015
9374433056
9374629022
9374166084
9374345014
-- Drain Assy
-- Drain Cap
9303029015
313166024302
Ref. Description Part number
OUTDOOR UNIT
16
17
11
12
13
14
15
