OUTDOOR UNIT
Compressor
2008.04.16 25
41
42
43
44
46
45
47
41 Compressor Assy 9377946010
46 Washer (Rubber)
47 Frange Nut
9377949011
9377950017
42 Rubber Seat
43 Terminal Packing
44
45
Holder
9377951014
9377948014
9377952011
Terminal Cover 9377947017
-- Compressor Cover B
-- Compressor Cover C
9374431052
9372067048
-- Compressor Cover A 9374430055
Ref. Description Part number
