Fujitsu ASY50-KM Design & Technical Manual

AOYG36KBTA5
Combination no. Unit 1 Unit 2 Unit 3 Unit 4 Unit 5 Total
53 12 12 12 — — 36
54 12 12 14 — — 38
55 12 12 18 — — 42
56 12 12 22 — — 46
57 12 12 24 — — 48
58 12 14 14 — — 40
59 12 14 18 — — 44
60 12 14 22 — — 48
61 12 14 24 — — 50
62 12 18 18 — — 48
63 12 18 22 — — 52
64 12 18 24 — — 54
65 14 14 14 — — 42
66 14 14 18 — — 46
67 14 14 22 — — 50
68 14 14 24 — — 52
69 14 18 18 — — 50
70 18 18 18 — — 54
71 7 7 7 7 — 28
72 7 7 7 9 — 30
73 7 7 7 12 — 33
74 7 7 7 14 — 35
75 7 7 7 18 — 39
76 7 7 7 22 — 43
77 7 7 7 24 — 45
78 7 7 9 9 — 32
79 7 7 9 12 — 35
80 7 7 9 14 — 37
81 7 7 9 18 — 41
82 7 7 9 22 — 45
83 7 7 9 24 — 47
84 7 7 12 12 — 38
85 7 7 12 14 — 40
86 7 7 12 18 — 44
87 7 7 12 22 — 48
88 7 7 12 24 — 50
89 7 7 14 14 — 42
90 7 7 14 18 — 46
91 7 7 14 22 — 50
92 7 7 14 24 — 52
93 7 7 18 18 — 50
94 7 9 9 9 — 34
95 7 9 9 12 — 37
96 7 9 9 14 — 39
97 7 9 9 18 — 43
98 7 9 9 22 — 47
99 7 9 9 24 — 49
100 7 9 12 12 — 40
101 7 9 12 14 — 42
102 7 9 12 18 — 46
103 7 9 12 22 — 50
104 7 9 12 24 — 52
105 7 9 14 14 — 44
106 7 9 14 18 — 48
107 7 9 14 22 — 52
- 8 -
1-1. Indoor unit connection patterns
1. Model lineup
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT MULTI-SPLIT TYPE

Fujitsu ASY50-KM Specifications

General

Brand	Fujitsu
Model	ASY50-KM
Category	Air Conditioner
Language	English
