4-7. Floor type
¢
Models: AGYG09–14KVCA
Unit: mm
600
200
Side view
Front view
740
- 64 -
4-7. Floor type
4. Dimensions
4-5 UNIT
MULTI-SPLIT TYPE
4-5 UNIT
MULTI-SPLIT TYPE
