Fujitsu ASY50-KM Design & Technical Manual

Power supply
(50 Hz, 230 V)
Indoor rated
Wiring spec. of connection
cable
(Indoor unit to outdoor
unit)
Type Model name
MCA
Input
power
FLA
Cross-
sectional
area
Limited
wiring
length
(A) (W) (A)
(mm
2
)
(m)
Wall mounted
ASYG07KETA
ASYG07KETA-B
0.25 23 0.20
1.5 26
ASYG09KETA
ASYG09KETA-B
0.30 27 0.24
ASYG12KETA
ASYG12KETA-B
0.30 27 0.24
ASYG14KETA
ASYG14KETA-B
0.38 33 0.30
ASYG07KETE
ASYG07KETE-B
0.25 23 0.20
ASYG09KETE
ASYG09KETE-B
0.30 27 0.24
ASYG12KETE
ASYG12KETE-B
0.30 27 0.24
ASYG14KETE
ASYG14KETE-B
0.38 33 0.30
ASYG07KETF
ASYG07KETF-B
0.25 23 0.20
ASYG09KETF
ASYG09KETF-B
0.30 27 0.24
ASYG12KETF
ASYG12KETF-B
0.30 27 0.24
ASYG14KETF
ASYG14KETF-B
0.38 33 0.30
Ceiling
ABYG18KRTA 0.39 37 0.21
1.5 26
ABYG22KRTA 0.49 46 0.25
Floor
AGYG09KVCA 0.19 16 0.15
1.5 26AGYG12KVCA 0.23 20 0.18
AGYG14KVCA 0.25 23 0.20
MCA: Minimum Circuit Ampacity = Maximum operating current (Full load)
FLA: Full Load Amperes (Fan motor)
