Combination of indoor unit
Rated capacity for each indoor
unit (kW)
Total capacity
(kW)
Input power (kW)
COP
(W/W)
Seasonal data
Room
Total
Room
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SCOP
(kWh/
kWh)
Energy
efficien-
cy class
1 2 3 4 1 2 3 4
7 9 14 14 44 1.54 1.96 3.05 3.05 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 9 14 18 48 1.40 1.80 2.80 3.60 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 12 12 12 43 1.56 2.68 2.68 2.68 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 12 12 14 45 1.49 2.56 2.56 2.99 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 12 12 18 49 1.37 2.35 2.35 3.53 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
7 12 14 14 47 1.43 2.45 2.86 2.86 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
9 9 9 9 36 2.40 2.40 2.40 2.40 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
9 9 9 12 39 2.22 2.22 2.22 2.94 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
9 9 9 14 41 2.11 2.11 2.11 3.27 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
9 9 9 18 45 1.92 1.92 1.92 3.84 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
9 9 12 12 42 2.06 2.06 2.74 2.74 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
9 9 12 14 44 1.96 1.96 2.62 3.06 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
9 9 12 18 48 1.80 1.80 2.40 3.60 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
9 9 14 14 46 1.88 1.88 2.92 2.92 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
9 12 12 12 45 1.92 2.56 2.56 2.56 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
9 12 12 14 47 1.84 2.45 2.45 2.86 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
9 12 14 14 49 1.77 2.35 2.74 2.74 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
12 12 12 12 48 2.40 2.40 2.40 2.40 3.0 9.60 11.2 0.30 2.11 2.95 4.55 6.5 4.6 A++
NOTES:
• 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h, 18: 18,000 Btu/h, 22: 22,000
Btu/h, 24: 24,000 Btu/h
• Values mentioned in the table are based on the following conditions:
– Power source of specifications: 230 V
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
– Heating: Indoor temperature of 20 °CDB, and outdoor temperature of 7 °CDB/6 °CWB.
• 2 or more indoor units should be connected.
• The total ability of connected a indoor unit is from 25,000 Btu up to 49,000 Btu.
- 393 -
6-1. Combinations
6. Capacity table
OUTDOOR UNIT AOYG30KBTA4
OUTDOOR UNIT
AOYG30KBTA4
