Fujitsu ASY50-KM Design & Technical Manual

Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB
12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB
kBtu/h °CDB TC IP TC IP TC IP TC IP TC IP TC IP
26
-10.0 7.3 1.71 8.2 1.74 8.7 1.76 9.3 1.78 9.9 1.80 10.2 1.81
0.0 7.3 1.78 8.2 1.81 8.7 1.83 9.3 1.85 9.9 1.87 10.2 1.88
5.0 7.3 1.75 8.2 1.78 8.7 1.79 9.3 1.81 9.9 1.84 10.2 1.84
10.0 7.3 1.86 8.2 1.89 8.7 1.91 9.3 1.93 9.9 1.95 10.2 1.96
15.0 7.3 1.77 8.2 1.80 8.7 1.81 9.3 1.83 9.9 1.86 10.2 1.87
20.0 7.3 1.67 8.2 1.70 8.7 1.72 9.3 1.74 9.9 1.76 10.2 1.76
25.0 7.3 2.02 8.2 2.06 8.7 2.08 9.3 2.10 9.9 2.12 10.2 2.13
30.0 7.3 2.42 8.2 2.47 8.7 2.49 9.3 2.51 9.9 2.54 10.2 2.56
35.0 7.3 2.81 8.2 2.86 8.7 2.88 9.3 2.91 9.9 2.95 10.2 2.96
40.0 6.0 2.37 6.8 2.42 7.2 2.44 7.7 2.46 8.2 2.49 8.5 2.50
46.0 6.0 1.94 6.8 1.97 7.2 1.99 7.7 2.01 8.2 2.04 8.5 2.05
25
-10.0 7.0 1.64 7.9 1.67 8.3 1.68 8.9 1.70 9.5 1.72 9.8 1.73
0.0 7.0 1.70 7.9 1.73 8.3 1.75 8.9 1.77 9.5 1.79 9.8 1.80
5.0 7.0 1.67 7.9 1.70 8.3 1.72 8.9 1.74 9.5 1.76 9.8 1.77
10.0 7.0 1.78 7.9 1.81 8.3 1.83 8.9 1.85 9.5 1.87 9.8 1.88
15.0 7.0 1.69 7.9 1.72 8.3 1.74 8.9 1.76 9.5 1.78 9.8 1.79
20.0 7.0 1.60 7.9 1.63 8.3 1.64 8.9 1.66 9.5 1.68 9.8 1.69
25.0 7.0 1.94 7.9 1.97 8.3 1.99 8.9 2.01 9.5 2.03 9.8 2.04
30.0 7.0 2.32 7.9 2.36 8.3 2.38 8.9 2.41 9.5 2.44 9.8 2.45
35.0 7.0 2.69 7.9 2.74 8.3 2.76 8.9 2.79 9.5 2.82 9.8 2.84
40.0 5.8 2.27 6.5 2.31 6.9 2.33 7.4 2.36 7.9 2.39 8.1 2.40
46.0 5.8 1.86 6.5 1.89 6.9 1.91 7.4 1.93 7.9 1.95 8.1 1.96
NOTES:
• TC: Total Capacity (kW), IP: Input Power (kW)
• Values mentioned in the table are based on the following conditions:
– Power source of specifications: 230 V
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
• 2 or more indoor units should be connected.
• The total ability of connected indoor unit is from 25,000 Btu/h up to 49,000 Btu/h.
• Input in the table are calculated based on the maximum indoor unit input combinations.
- 397 -
6-2. Cooling capacity
6. Capacity table
OUTDOOR UNIT AOYG30KBTA4
OUTDOOR UNIT
AOYG30KBTA4

Fujitsu ASY50-KM Specifications

General

Brand	Fujitsu
Model	ASY50-KM
Category	Air Conditioner
Language	English
