Fujitsu ASY50-KM Design & Technical Manual


Mini duct type
Model: ARXG07KSLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
-5.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
0.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
5.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
10.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
15.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
20.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
25.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
30.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
35.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
40.0 1.62 0.93 1.83 1.06 1.93 1.22 2.07 1.37 2.21 1.50 2.28 1.72
46.0 1.28 0.58 1.45 0.66 1.53 0.76 1.64 0.86 1.75 0.94 1.81 1.08
Model: ARXG09KSLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
-5.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
0.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
5.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
10.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
15.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
20.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
25.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
30.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
35.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
40.0 2.08 1.10 2.35 1.25 2.47 1.44 2.65 1.62 2.83 1.77 2.92 2.03
46.0 1.64 0.69 1.86 0.79 1.96 0.91 2.10 1.02 2.24 1.11 2.31 1.27
Model: ARXG12KSLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
-5.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
0.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
5.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
10.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
15.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
20.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
25.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
30.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
35.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
40.0 2.79 1.48 3.15 1.69 3.32 1.94 3.56 2.18 3.80 2.38 3.92 2.73
46.0 2.21 0.93 2.50 1.06 2.63 1.22 2.82 1.37 3.01 1.49 3.11 1.71
Model: ARXG14KSLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.92 2.41 4.43 2.74 4.67 3.16 5.00 3.55 5.35 3.88 5.51 4.45
-5.0 3.92 2.41 4.43 2.74 4.67 3.16 5.00 3.55 5.35 3.88 5.51 4.45
0.0 3.92 2.41 4.43 2.74 4.67 3.16 5.00 3.55 5.35 3.88 5.51 4.45
5.0 3.92 2.41 4.43 2.74 4.67 3.16 5.00 3.55 5.35 3.88 5.51 4.45
10.0 3.92 2.41 4.43 2.74 4.67 3.16 5.00 3.55 5.35 3.88 5.51 4.45
15.0 3.92 2.41 4.43 2.74 4.67 3.16 5.00 3.55 5.35 3.88 5.51 4.45
20.0 3.92 2.41 4.43 2.74 4.67 3.16 5.00 3.55 5.35 3.88 5.51 4.45
25.0 3.92 2.41 4.43 2.74 4.67 3.16 5.00 3.55 5.35 3.88 5.51 4.45
30.0 3.92 2.41 4.43 2.74 4.67 3.16 5.00 3.55 5.35 3.88 5.51 4.45
35.0 3.92 2.41 4.43 2.74 4.67 3.16 5.00 3.55 5.35 3.88 5.51 4.45
40.0 3.24 1.65 3.67 1.88 3.87 2.16 4.14 2.43 4.42 2.66 4.56 3.05
46.0 2.57 1.03 2.90 1.18 3.06 1.36 3.28 1.52 3.50 1.67 3.61 1.91
- 400 -
6-2. Cooling capacity
6. Capacity table
OUTDOOR UNIT AOYG30KBTA4
OUTDOOR UNIT
AOYG30KBTA4

Fujitsu ASY50-KM Specifications

General

Brand	Fujitsu
Model	ASY50-KM
Category	Air Conditioner
Language	English
