Fujitsu ASY50-KM Design & Technical Manual


Slim duct type
Model: ARXG07KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
-5.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
0.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
5.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
10.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
15.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
20.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
25.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
30.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
35.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
40.0 1.62 0.93 1.83 1.06 1.93 1.22 2.07 1.37 2.21 1.50 2.28 1.72
46.0 1.28 0.58 1.45 0.66 1.53 0.76 1.64 0.86 1.75 0.94 1.81 1.08
Model: ARXG09KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
-5.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
0.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
5.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
10.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
15.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
20.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
25.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
30.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
35.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
40.0 2.08 1.14 2.35 1.30 2.47 1.50 2.65 1.69 2.83 1.85 2.92 2.11
46.0 1.64 0.72 1.86 0.82 1.96 0.94 2.10 1.06 2.24 1.16 2.31 1.33
Model: ARXG12KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
-5.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
0.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
5.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
10.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
15.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
20.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
25.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
30.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
35.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
40.0 2.79 1.56 3.15 1.78 3.32 2.04 3.56 2.30 3.80 2.51 3.92 2.88
46.0 2.21 0.98 2.50 1.11 2.63 1.28 2.82 1.44 3.01 1.58 3.11 1.80
Model: ARXG14KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
-5.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
0.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
5.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
10.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
15.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
20.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
25.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
30.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
35.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
40.0 3.24 1.72 3.67 1.96 3.87 2.26 4.14 2.53 4.42 2.77 4.56 3.18
46.0 2.57 1.08 2.90 1.23 3.06 1.41 3.28 1.59 3.50 1.74 3.61 1.99
- 402 -
6-2. Cooling capacity
6. Capacity table
