Fujitsu ASY50-KM Design & Technical Manual


Floor type
Model: AGYG09KVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
-5.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
0.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
5.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
10.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
15.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
20.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
25.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
30.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
35.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
40.0 2.08 1.17 2.35 1.34 2.47 1.54 2.65 1.73 2.83 1.89 2.92 2.17
46.0 1.64 0.74 1.86 0.84 1.96 0.97 2.10 1.09 2.24 1.19 2.31 1.36
Model: AGYG12KVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
-5.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
0.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
5.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
10.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
15.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
20.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
25.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
30.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
35.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
40.0 2.79 1.48 3.15 1.69 3.32 1.94 3.56 2.18 3.80 2.38 3.92 2.73
46.0 2.21 0.93 2.50 1.06 2.63 1.22 2.82 1.37 3.01 1.49 3.11 1.71
Model: AGYG14KVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
-5.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
0.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
5.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
10.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
15.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
20.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
25.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
30.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
35.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
40.0 3.24 1.67 3.67 1.91 3.87 2.19 4.14 2.47 4.42 2.70 4.56 3.09
46.0 2.57 1.05 2.90 1.20 3.06 1.38 3.28 1.55 3.50 1.69 3.61 1.94
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 417 -
6-2. Cooling capacity
6. Capacity table
OUTDOOR UNIT AOYG30KBTA4
OUTDOOR UNIT
AOYG30KBTA4
