Fujitsu ASY50-KM Design & Technical Manual

Indoor unit connecting
capacity
Outdoor temperature
Indoor temperature
16.0 °CDB 18.0 °CDB 20.0 °CDB 22.0 °CDB 24.0 °CDB
kBtu/h °CDB °CWB TC IP TC IP TC IP TC IP TC IP
32
-15.0 -16.0 6.1 2.96 6.0 3.02 5.9 3.08 5.7 3.14 5.6 3.20
-10.0 -11.0 7.6 3.24 7.5 3.31 7.3 3.38 7.1 3.45 6.9 3.51
-5.0 -7.0 9.1 3.13 8.9 3.20 8.7 3.26 8.4 3.33 8.2 3.39
0.0 -2.0 10.7 3.35 10.4 3.42 10.2 3.49 9.9 3.56 9.7 3.63
5.0 3.0 11.8 3.21 11.5 3.27 11.2 3.34 10.9 3.41 10.6 3.47
7.0 6.0 11.8 2.91 11.5 2.97 11.2 3.03 10.9 3.09 10.6 3.15
10.0 8.0 11.8 2.80 11.5 2.86 11.2 2.92 10.9 2.98 10.6 3.04
15.0 10.0 11.8 2.44 11.5 2.50 11.2 2.55 10.9 2.60 10.6 2.65
20.0 15.0 11.8 2.06 11.5 2.10 11.2 2.14 10.9 2.19 10.6 2.23
24.0 18.0 11.8 1.87 11.5 1.91 11.2 1.94 10.9 1.98 10.6 2.02
31
-15.0 -16.0 6.1 2.96 6.0 3.02 5.9 3.08 5.7 3.14 5.6 3.20
-10.0 -11.0 7.6 3.24 7.5 3.31 7.3 3.38 7.1 3.45 6.9 3.51
-5.0 -7.0 9.1 3.13 8.9 3.20 8.7 3.26 8.4 3.33 8.2 3.39
0.0 -2.0 10.7 3.35 10.4 3.42 10.2 3.49 9.9 3.56 9.7 3.63
5.0 3.0 11.8 3.21 11.5 3.27 11.2 3.34 10.9 3.41 10.6 3.47
7.0 6.0 11.8 2.91 11.5 2.97 11.2 3.03 10.9 3.09 10.6 3.15
10.0 8.0 11.8 2.80 11.5 2.86 11.2 2.92 10.9 2.98 10.6 3.04
15.0 10.0 11.8 2.44 11.5 2.50 11.2 2.55 10.9 2.60 10.6 2.65
20.0 15.0 11.8 2.06 11.5 2.10 11.2 2.14 10.9 2.19 10.6 2.23
24.0 18.0 11.8 1.87 11.5 1.91 11.2 1.94 10.9 1.98 10.6 2.02
30
-15.0 -16.0 6.1 2.96 6.0 3.02 5.9 3.08 5.7 3.14 5.6 3.20
-10.0 -11.0 7.6 3.24 7.5 3.31 7.3 3.38 7.1 3.45 6.9 3.51
-5.0 -7.0 9.1 3.13 8.9 3.20 8.7 3.26 8.4 3.33 8.2 3.39
0.0 -2.0 10.7 3.35 10.4 3.42 10.2 3.49 9.9 3.56 9.7 3.63
5.0 3.0 11.8 3.21 11.5 3.27 11.2 3.34 10.9 3.41 10.6 3.47
7.0 6.0 11.8 2.91 11.5 2.97 11.2 3.03 10.9 3.09 10.6 3.15
10.0 8.0 11.8 2.80 11.5 2.86 11.2 2.92 10.9 2.98 10.6 3.04
15.0 10.0 11.8 2.44 11.5 2.50 11.2 2.55 10.9 2.60 10.6 2.65
20.0 15.0 11.8 2.06 11.5 2.10 11.2 2.14 10.9 2.19 10.6 2.23
24.0 18.0 11.8 1.87 11.5 1.91 11.2 1.94 10.9 1.98 10.6 2.02
29
-15.0 -16.0 6.1 2.96 6.0 3.02 5.9 3.08 5.7 3.14 5.6 3.20
-10.0 -11.0 7.6 3.24 7.5 3.31 7.3 3.38 7.1 3.45 6.9 3.51
-5.0 -7.0 9.1 3.13 8.9 3.20 8.7 3.26 8.4 3.33 8.2 3.39
0.0 -2.0 10.7 3.35 10.4 3.42 10.2 3.49 9.9 3.56 9.7 3.63
5.0 3.0 11.8 3.21 11.5 3.27 11.2 3.34 10.9 3.41 10.6 3.47
7.0 6.0 11.8 2.91 11.5 2.97 11.2 3.03 10.9 3.09 10.6 3.15
10.0 8.0 11.8 2.80 11.5 2.86 11.2 2.92 10.9 2.98 10.6 3.04
15.0 10.0 11.8 2.44 11.5 2.50 11.2 2.55 10.9 2.60 10.6 2.65
20.0 15.0 11.8 2.06 11.5 2.10 11.2 2.14 10.9 2.19 10.6 2.23
24.0 18.0 11.8 1.87 11.5 1.91 11.2 1.94 10.9 1.98 10.6 2.02
28
-15.0 -16.0 6.1 2.96 6.0 3.02 5.9 3.08 5.7 3.14 5.6 3.20
-10.0 -11.0 7.6 3.24 7.5 3.31 7.3 3.38 7.1 3.45 6.9 3.51
-5.0 -7.0 9.1 3.13 8.9 3.20 8.7 3.26 8.4 3.33 8.2 3.39
0.0 -2.0 10.7 3.35 10.4 3.42 10.2 3.49 9.9 3.56 9.7 3.63
5.0 3.0 11.8 3.21 11.5 3.27 11.2 3.34 10.9 3.41 10.6 3.47
7.0 6.0 11.8 2.91 11.5 2.97 11.2 3.03 10.9 3.09 10.6 3.15
10.0 8.0 11.8 2.80 11.5 2.86 11.2 2.92 10.9 2.98 10.6 3.04
15.0 10.0 11.8 2.44 11.5 2.50 11.2 2.55 10.9 2.60 10.6 2.65
20.0 15.0 11.8 2.06 11.5 2.10 11.2 2.14 10.9 2.19 10.6 2.23
24.0 18.0 11.8 1.87 11.5 1.91 11.2 1.94 10.9 1.98 10.6 2.02
27
-15.0 -16.0 5.9 2.76 5.8 2.81 5.6 2.87 5.5 2.93 5.4 2.99
-10.0 -11.0 7.4 3.03 7.2 3.09 7.0 3.15 6.8 3.22 6.7 3.28
-5.0 -7.0 8.8 2.92 8.6 2.98 8.4 3.04 8.1 3.10 7.9 3.16
0.0 -2.0 10.3 3.13 10.1 3.19 9.8 3.26 9.6 3.32 9.3 3.39
5.0 3.0 11.3 2.99 11.1 3.05 10.8 3.12 10.5 3.18 10.3 3.24
7.0 6.0 11.3 2.72 11.1 2.77 10.8 2.83 10.5 2.89 10.3 2.94
10.0 8.0 11.3 2.61 11.1 2.67 10.8 2.72 10.5 2.78 10.3 2.83
15.0 10.0 11.3 2.28 11.1 2.33 10.8 2.38 10.5 2.42 10.3 2.47
20.0 15.0 11.3 1.92 11.1 1.96 10.8 2.00 10.5 2.04 10.3 2.08
24.0 18.0 11.3 1.74 11.1 1.78 10.8 1.81 10.5 1.85 10.3 1.89
26
-15.0 -16.0 5.7 2.64 5.6 2.70 5.4 2.75 5.3 2.81 5.2 2.86
-10.0 -11.0 7.1 2.90 6.9 2.96 6.8 3.02 6.6 3.08 6.4 3.14
-5.0 -7.0 8.4 2.80 8.2 2.86 8.0 2.91 7.8 2.97 7.6 3.03
0.0 -2.0 9.9 2.99 9.7 3.06 9.5 3.12 9.2 3.18 9.0 3.24
5.0 3.0 10.9 2.86 10.7 2.92 10.4 2.98 10.1 3.04 9.9 3.10
7.0 6.0 10.9 2.60 10.7 2.66 10.4 2.71 10.1 2.76 9.9 2.82
10.0 8.0 10.9 2.50 10.7 2.56 10.4 2.61 10.1 2.66 9.9 2.71
15.0 10.0 10.9 2.18 10.7 2.23 10.4 2.27 10.1 2.32 9.9 2.37
20.0 15.0 10.9 1.84 10.7 1.88 10.4 1.92 10.1 1.95 9.9 1.99
24.0 18.0 10.9 1.67 10.7 1.70 10.4 1.74 10.1 1.77 9.9 1.81
25
-15.0 -16.0 5.5 2.52 5.4 2.58 5.2 2.63 5.1 2.68 5.0 2.73
-10.0 -11.0 6.8 2.77 6.7 2.83 6.5 2.88 6.3 2.94 6.2 3.00
-5.0 -7.0 8.1 2.67 7.9 2.73 7.7 2.78 7.5 2.84 7.4 2.90
0.0 -2.0 9.6 2.86 9.3 2.92 9.1 2.98 8.9 3.04 8.6 3.10
5.0 3.0 10.5 2.74 10.3 2.79 10.0 2.85 9.8 2.91 9.5 2.97
7.0 6.0 10.5 2.49 10.3 2.54 10.0 2.59 9.8 2.64 9.5 2.69
10.0 8.0 10.5 2.39 10.3 2.44 10.0 2.49 9.8 2.54 9.5 2.59
15.0 10.0 10.5 2.09 10.3 2.13 10.0 2.17 9.8 2.22 9.5 2.26
20.0 15.0 10.5 1.76 10.3 1.79 10.0 1.83 9.8 1.87 9.5 1.90
24.0 18.0 10.5 1.59 10.3 1.63 10.0 1.66 9.8 1.69 9.5 1.73
- 420 -
6-3. Heating capacity
6. Capacity table
OUTDOOR UNIT AOYG30KBTA4
OUTDOOR UNIT
AOYG30KBTA4
