Fujitsu ASY50-KM Design & Technical Manual

Combination of indoor unit Rated capacity for each indoor unit (kW)
Total capacity
(kW)
Input power (kW)
EER
(W/W)
Seasonal data
Room
Total
Room
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SEER
(kWh/kWh)
Energy effi-
ciency class
1 2 3 4 5 1 2 3 4 5
7 7 7 14 — 35 1.90 1.90 1.90 3.80 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 7 18 — 39 1.71 1.71 1.71 4.37 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 7 22 — 43 1.55 1.55 1.55 4.85 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 7 24 — 45 1.48 1.48 1.48 5.06 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 9 9 — 32 2.00 2.00 2.50 2.50 — 3.0 9.00 11.0 0.30 2.49 3.45 3.62 9.0 8.4 A++
7 7 9 12 — 35 1.90 1.90 2.44 3.26 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 9 14 — 37 1.80 1.80 2.31 3.59 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 9 18 — 41 1.62 1.62 2.09 4.17 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 9 22 — 45 1.48 1.48 1.90 4.64 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 9 24 — 47 1.41 1.41 1.82 4.86 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 12 12 — 38 1.75 1.75 3.00 3.00 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 12 14 — 40 1.66 1.66 2.85 3.33 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 12 18 — 44 1.51 1.51 2.59 3.89 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 12 22 — 48 1.39 1.39 2.38 4.34 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 12 24 — 50 1.33 1.33 2.28 4.56 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 14 14 — 42 1.58 1.58 3.17 3.17 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 14 18 — 46 1.45 1.45 2.89 3.71 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 14 22 — 50 1.33 1.33 2.66 4.18 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 14 24 — 52 1.28 1.28 2.56 4.38 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 18 18 — 50 1.33 1.33 3.42 3.42 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 9 9 9 — 34 2.00 2.50 2.50 2.50 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 9 9 12 — 37 1.80 2.31 2.31 3.08 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 9 9 14 — 39 1.71 2.19 2.19 3.41 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 9 9 18 — 43 1.54 1.99 1.99 3.98 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 9 9 22 — 47 1.41 1.82 1.82 4.45 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 9 9 24 — 49 1.36 1.74 1.74 4.66 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 9 12 12 — 40 1.66 2.14 2.85 2.85 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 9 12 14 — 42 1.58 2.04 2.71 3.17 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 9 12 18 — 46 1.44 1.86 2.48 3.72 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 9 12 22 — 50 1.33 1.71 2.28 4.18 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 9 12 24 — 52 1.28 1.64 2.19 4.39 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 9 14 14 — 44 1.51 1.95 3.02 3.02 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 9 14 18 — 48 1.39 1.78 2.77 3.56 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 9 14 22 — 52 1.28 1.64 2.56 4.02 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 9 14 24 — 54 1.23 1.58 2.46 4.23 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 9 18 18 — 52 1.28 1.64 3.29 3.29 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 12 12 12 — 43 1.55 2.65 2.65 2.65 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 12 12 14 — 45 1.48 2.53 2.53 2.96 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 12 12 18 — 49 1.35 2.33 2.33 3.49 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 12 14 14 — 47 1.41 2.43 2.83 2.83 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 12 14 18 — 51 1.30 2.24 2.61 3.35 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 14 14 14 — 49 1.37 2.71 2.71 2.71 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 14 14 18 — 53 1.25 2.51 2.51 3.23 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 9 9 9 — 36 2.38 2.38 2.38 2.38 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 9 9 12 — 39 2.19 2.19 2.19 2.93 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 9 9 14 — 41 2.09 2.09 2.09 3.23 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 9 9 18 — 45 1.90 1.90 1.90 3.80 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 9 9 22 — 49 1.74 1.74 1.74 4.28 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 9 9 24 — 51 1.68 1.68 1.68 4.46 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 9 12 12 — 42 2.04 2.04 2.71 2.71 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 9 12 14 — 44 1.94 1.94 2.59 3.03 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 9 12 18 — 48 1.78 1.78 2.38 3.56 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 9 12 22 — 52 1.64 1.64 2.19 4.03 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 9 12 24 — 54 1.58 1.58 2.11 4.23 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 9 14 14 — 46 1.86 1.86 2.89 2.89 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 9 14 18 — 50 1.71 1.71 2.66 3.42 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 9 18 18 — 54 1.58 1.58 3.17 3.17 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 12 12 12 — 45 1.91 2.53 2.53 2.53 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 12 12 14 — 47 1.81 2.43 2.43 2.83 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 12 12 18 — 51 1.67 2.24 2.24 3.35 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 12 14 14 — 49 1.74 2.34 2.71 2.71 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 12 14 18 — 53 1.61 2.15 2.51 3.23 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
9 14 14 14 — 51 1.67 2.61 2.61 2.61 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
12 12 12 12 — 48 2.38 2.38 2.38 2.38 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
12 12 12 14 — 50 2.28 2.28 2.28 2.66 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
12 12 12 18 — 54 2.11 2.11 2.11 3.17 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
12 12 14 14 — 52 2.19 2.19 2.56 2.56 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
12 14 14 14 — 54 2.12 2.46 2.46 2.46 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
7 7 7 7 7 35 1.90 1.90 1.90 1.90 1.90 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 7 7 9 37 1.80 1.80 1.80 1.80 2.30 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 7 7 12 40 1.66 1.66 1.66 1.66 2.86 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 7 7 14 42 1.58 1.58 1.58 1.58 3.18 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 7 7 18 46 1.45 1.45 1.45 1.45 3.70 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 7 7 22* 28 1.33 1.33 1.33 1.33 4.18 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 7 7 24 52 1.28 1.28 1.28 1.28 4.38 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 7 9 9 39 1.70 1.70 1.70 2.20 2.20 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 7 9 12 42 1.58 1.58 1.58 2.04 2.72 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 7 9 14 44 1.51 1.51 1.51 1.94 3.03 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 7 9 18 48 1.39 1.39 1.39 1.77 3.56 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 7 9 22* 30 1.28 1.28 1.28 1.64 4.02 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 7 9 24 54 1.23 1.23 1.23 1.58 4.23 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 7 12 12 45 1.48 1.48 1.48 2.53 2.53 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 7 12 14 47 1.41 1.41 1.41 2.43 2.84 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 7 12 18 51 1.30 1.30 1.30 2.24 3.36 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 7 14 14 49 1.36 1.36 1.36 2.71 2.71 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 7 14 18 53 1.25 1.25 1.25 2.51 3.24 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 9 9 9 41 1.63 1.63 2.08 2.08 2.08 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 9 9 12 44 1.51 1.51 1.94 1.94 2.60 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
7 7 9 9 14 46 1.45 1.45 1.86 1.86 2.88 3.0 9.50 11.0 0.30 2.50 3.45 3.80 9.5 8.5 A+++
- 479 -
6-1. Combinations
6. Capacity table
OUTDOOR UNIT AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5

Fujitsu ASY50-KM Specifications

General

Brand	Fujitsu
Model	ASY50-KM
Category	Air Conditioner
Language	English
