Fujitsu ASY50-KM Design & Technical Manual


Heating
Combination of indoor unit Rated capacity for each indoor unit (kW)
Total capacity
(kW)
Input power (kW)
COP
(W/W)
Seasonal data
Room
Total
Room
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SCOP
(kWh/kWh)
Energy ef-
ficiency
class
1 2 3 4 5 1 2 3 4 5
7 24 — — — 31 2.39 8.21 — — — 3.5 10.60 12.0 0.25 2.65 3.25 4.00 7.0 4.3 A+
9 22 — — — 31 3.00 7.20 — — — 3.5 10.20 12.0 0.25 2.52 3.25 4.04 6.8 4.3 A+
9 24 — — — 33 2.89 7.71 — — — 3.5 10.60 12.0 0.25 2.65 3.25 4.00 7.0 4.3 A+
12 22 — — — 34 3.74 6.86 — — — 3.5 10.60 12.0 0.25 2.65 3.25 4.00 7.0 4.3 A+
12 24 — — — 36 3.53 7.07 — — — 3.5 10.60 12.0 0.25 2.65 3.25 4.00 7.0 4.3 A+
14 22 — — — 36 4.12 6.48 — — — 3.5 10.60 12.0 0.25 2.65 3.25 4.00 7.0 4.3 A+
14 24 — — — 38 3.91 6.69 — — — 3.5 10.60 12.0 0.25 2.65 3.25 4.00 7.0 4.3 A+
18 18 — — — 36 5.30 5.30 — — — 3.5 10.60 12.0 0.25 2.65 3.25 4.00 7.0 4.3 A+
18 22 — — — 40 4.77 5.83 — — — 3.5 10.60 12.0 0.25 2.65 3.25 4.00 7.0 4.3 A+
18 24 — — — 42 4.54 6.06 — — — 3.5 10.60 12.0 0.25 2.65 3.25 4.00 7.0 4.3 A+
22 22 — — — 44 5.30 5.30 — — — 3.5 10.60 12.0 0.25 2.65 3.25 4.00 7.0 4.3 A+
22 24 — — — 46 5.07 5.53 — — — 3.5 10.60 12.0 0.25 2.65 3.25 4.00 7.0 4.3 A+
24 24 — — — 48 5.30 5.30 — — — 3.5 10.60 12.0 0.25 2.65 3.25 4.00 7.0 4.3 A+
7 7 14 — — 28 2.40 2.40 4.80 — — 3.5 9.60 11.2 0.25 2.25 2.87 4.26 6.5 4.5 A+
7 7 18 — — 32 2.32 2.32 5.96 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 7 22 — — 36 2.06 2.06 6.48 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 7 24 — — 38 1.95 1.95 6.70 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 9 12 — — 28 2.40 3.00 4.20 — — 3.5 9.60 11.2 0.25 2.25 2.87 4.26 6.5 4.5 A+
7 9 14 — — 30 2.40 3.00 4.80 — — 3.5 10.20 12.0 0.25 2.42 3.25 4.21 6.8 4.4 A+
7 9 18 — — 34 2.18 2.81 5.61 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 9 22 — — 38 1.95 2.51 6.14 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 9 24 — — 40 1.85 2.39 6.36 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 12 12 — — 31 2.40 4.10 4.10 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 12 14 — — 33 2.25 3.85 4.50 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 12 18 — — 37 2.00 3.44 5.16 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 12 22 — — 41 1.81 3.10 5.69 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 12 24 — — 43 1.72 2.96 5.92 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 14 14 — — 35 2.12 4.24 4.24 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 14 18 — — 39 1.90 3.81 4.89 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 14 22 — — 43 1.73 3.45 5.42 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 14 24 — — 45 1.65 3.30 5.65 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 18 18 — — 43 1.72 4.44 4.44 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 18 22 — — 47 1.58 4.06 4.96 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 18 24 — — 49 1.51 3.89 5.20 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
9 9 9 — — 27 3.00 3.00 3.00 — — 3.5 9.00 10.8 0.25 2.09 2.70 4.31 6.0 4.5 A+
9 9 12 — — 30 3.00 3.00 4.20 — — 3.5 10.20 12.0 0.25 2.42 3.25 4.21 6.8 4.4 A+
9 9 14 — — 32 2.98 2.98 4.64 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
9 9 18 — — 36 2.65 2.65 5.30 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
9 9 22 — — 40 2.39 2.39 5.82 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
9 9 24 — — 42 2.27 2.27 6.06 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
9 12 12 — — 33 2.90 3.85 3.85 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
9 12 14 — — 35 2.73 3.63 4.24 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
9 12 18 — — 39 2.45 3.26 4.89 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
9 12 22 — — 43 2.22 2.96 5.42 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
9 12 24 — — 45 2.12 2.83 5.65 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
9 14 14 — — 37 2.58 4.01 4.01 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
9 14 18 — — 41 2.33 3.62 4.65 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
9 14 22 — — 45 2.12 3.30 5.18 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
9 14 24 — — 47 2.03 3.16 5.41 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
9 18 18 — — 45 2.12 4.24 4.24 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
9 18 22 — — 49 1.95 3.89 4.76 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
9 18 24 — — 51 1.87 3.74 4.99 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
12 12 12 — — 36 3.53 3.53 3.53 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
12 12 14 — — 38 3.35 3.35 3.90 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
12 12 18 — — 42 3.03 3.03 4.54 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
12 12 22 — — 46 2.77 2.77 5.06 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
12 12 24 — — 48 2.65 2.65 5.30 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
12 14 14 — — 40 3.18 3.71 3.71 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
12 14 18 — — 44 2.89 3.37 4.34 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
12 14 22 — — 48 2.65 3.09 4.86 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
12 14 24 — — 50 2.54 2.97 5.09 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
12 18 18 — — 48 2.64 3.98 3.98 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
12 18 22 — — 52 2.45 3.67 4.48 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
12 18 24 — — 54 2.36 3.53 4.71 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
14 14 14 — — 42 3.53 3.53 3.53 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
14 14 18 — — 46 3.23 3.23 4.14 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
14 14 22 — — 50 2.97 2.97 4.66 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
14 14 24 — — 52 2.85 2.85 4.90 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
14 18 18 — — 50 2.96 3.82 3.82 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
18 18 18 — — 54 3.53 3.53 3.53 — — 3.5 10.60 12.0 0.25 2.54 3.25 4.18 7.0 4.4 A+
7 7 7 7 — 28 2.40 2.40 2.40 2.40 — 3.5 9.60 11.2 0.25 2.17 2.87 4.42 6.5 4.6 A++
7 7 7 9 — 30 2.40 2.40 2.40 3.00 — 3.5 10.20 12.0 0.25 2.33 3.25 4.37 6.8 4.5 A+
7 7 7 12 — 33 2.25 2.25 2.25 3.85 — 3.5 10.60 12.0 0.25 2.44 3.25 4.34 7.0 4.5 A+
7 7 7 14 — 35 2.12 2.12 2.12 4.24 — 3.5 10.60 12.0 0.25 2.44 3.25 4.34 7.0 4.5 A+
7 7 7 18 — 39 1.90 1.90 1.90 4.90 — 3.5 10.60 12.0 0.25 2.44 3.25 4.34 7.0 4.5 A+
7 7 7 22 — 43 1.73 1.73 1.73 5.41 — 3.5 10.60 12.0 0.25 2.44 3.25 4.34 7.0 4.5 A+
7 7 7 24 — 45 1.65 1.65 1.65 5.65 — 3.5 10.60 12.0 0.25 2.44 3.25 4.34 7.0 4.5 A+
7 7 9 9 — 32 2.32 2.32 2.98 2.98 — 3.5 10.60 12.0 0.25 2.44 3.25 4.34 7.0 4.5 A+
7 7 9 12 — 35 2.12 2.12 2.73 3.63 — 3.5 10.60 12.0 0.25 2.44 3.25 4.34 7.0 4.5 A+
7 7 9 14 — 37 2.01 2.01 2.57 4.01 — 3.5 10.60 12.0 0.25 2.44 3.25 4.34 7.0 4.5 A+
7 7 9 18 — 41 1.81 1.81 2.33 4.65 — 3.5 10.60 12.0 0.25 2.44 3.25 4.34 7.0 4.5 A+
7 7 9 22 — 45 1.65 1.65 2.12 5.18 — 3.5 10.60 12.0 0.25 2.44 3.25 4.34 7.0 4.5 A+
7 7 9 24 — 47 1.58 1.58 2.03 5.41 — 3.5 10.60 12.0 0.25 2.44 3.25 4.34 7.0 4.5 A+
7 7 12 12 — 38 1.95 1.95 3.35 3.35 — 3.5 10.60 12.0 0.25 2.44 3.25 4.34 7.0 4.5 A+
7 7 12 14 — 40 1.86 1.86 3.17 3.71 — 3.5 10.60 12.0 0.25 2.44 3.25 4.34 7.0 4.5 A+
7 7 12 18 — 44 1.69 1.69 2.88 4.34 — 3.5 10.60 12.0 0.25 2.44 3.25 4.34 7.0 4.5 A+
